Caple WI6150 - Fitting a Kitchen Plinth

19Instruction manual Wi6150 & Wi6155Please keep this instruction manual for future reference
FITTING A KITCHEN PLINTH
The model is also supplied with a slot-on plinth grille if the previous method/grille is not
preferred. A H55mm vent slot is required in the plinth to ensure air is able to ventilate correctly.
See diagram below.
NOTE: Failure to include this vent slot will invalidate the guarantee.
55mm
490mm
R25
