Carel FCP/1 User Manual

FCP manual
Code +030220391 – rel 1.2 25/03/08
29
STID input ID1 status
type and Carel supervisor address digital var. (read only) 17
Modbus address read coil 17
resolution and unit of measure 1
range 0/1
default --
Variable used to read the status of digital input ID1.
STID=0 open
STID=1 closed
STD1 dipswitch 1 status
type and Carel supervisor address digital var. (read only) 18
Modbus address read coil 18
resolution and unit of measure 1
range 0/1
default --
Variable used to read the position of dipswitch 1.
STD1=0 Off
STD1=1 On
STD2 dipswitch 2 status
type and Carel supervisor address digital var. (read only) 19
Modbus address read coil 19
resolution and unit of measure 1
range 0/1
default --
Variable used to read the position of dipswitch 2.
STD2=0 Off
STD2=1 On
STD3 dipswitch 3 status
type and Carel supervisor address digital var. (read only) 20
Modbus address read coil 20
resolution and unit of measure 1
range 0/1
default --
Variable used to read the position of dipswitch 3.
STD3=0 Off
STD3=1 On
STD4 dipswitch 4 status
type and Carel supervisor address digital var. (read only) 21
Modbus address read coil 21
resolution and unit of measure 1
range 0/1
default --
Variable used to read the position of dipswitch 4.
STD4=0 Off
STD4=1 On
ALRM alarm status
type and Carel supervisor address digital var. (read only) 22
Modbus address read coil 22
resolution and unit of measure 1
range 0/1
default --
Variable used to read the status of the alarm.
ALRM=0 inactive
ALRM=1 active
The alarm may be signalled externally, associated with the digital input, or due to a fault on probes B1 or B2.
PB1A probe B1 alarm status
type and Carel supervisor address digital var. (read only) 23
Modbus address read coil 23
resolution and unit of measure 1
range 0/1
default --
Variable used to read the status of the probe B1 fault alarm.
PB1A=0 inactive
PB1A =1 active
The alarm is activated automatically if the value read by probe B1 is outside of the range of possible values, typically due to disconnection or short-circuit. The alarm is only detected if probe B1 is
enabled. The alarm is not detected if slave mode is selected.
