FCP manual
Code +030220391 – rel 1.2 25/03/08
12
4.2 Default settings
The functions that are available by setting the parameters are mostly disabled by default, as they need to be set based on the specific application.
Set the set point, differential, minimum and maximum output by trimmer (modifiable by dipswitch)
Digital input ID1 external alarm (modifiable by dipswitch)
Two circuit inactive (modifiable by dipswitch)
Cut-off inactive (modifiable by dipswitch)
Input B1 Ratiometric pressure probe
Input B2 Ratiometric pressure probe
Input B3
NTC temperature probe 10kΩ
Digital input ID1 Normally closed
Output in the event of alarms 100%
Direct/Reverse control mode Direct
Slave mode inactive
Speed-up active (duration 2 sec)
Output saturation inactive
Outside temperature compensation (feedforward) inactive
PI control inactive
Phase control function short impulse
Output ramp 1 s
Output linearisation active
Table 4.e
