Carel FCPM0420A0 User Manual

FCP manual
Code +030220391 – rel 1.2 25/03/08
24
tSET SET trimmer setting
type and Carel supervisor address integer var. (read only) 31
Modbus address read register 131
resolution and unit of measure 1%
range 0 to 100
default --
Variable used to read the value set by the trimmer
tDIF DIF trimmer setting
type and Carel supervisor address integer var. (read only) 32
Modbus address read register 132
resolution and unit of measure 1%
range 0 to 20
default --
Variable used to read the value set by the trimmer
tMIN MIN trimmer setting
type and Carel supervisor address integer var. (read only) 33
Modbus address read register 133
resolution and unit of measure 1%
range 0 to 100
default --
Variable used to read the value set by the trimmer
tMAX trimmer MAX setting
type and Carel supervisor address integer var. (read only) 34
Modbus address read register 134
resolution and unit of measure 1%
range 0 to 100
default --
Variable used to read the value set by the trimmer.
PB1R probe B1 reading in %
type and Carel supervisor address integer var. (read only) 35
Modbus address read register 135
resolution and unit of measure 1%
range 0 to 100
default --
Variable used to read the value measured by probe B1 expressed as a % of the range of measurement.
Range of measurement:
ratiometric pressure probes pressure interval specified by the manufacturer of the probe
Carel NTC temp. probe 10k
Ω temperature range defined by parameters T0L and T0H
Carel NTC temp. probe 50k
Ω temperature interval defined the parameters T1L and T1H
0/10 V signal 0/10V or 0.5/9.5V depending on the slave mode set
PB2R probe B2 reading in %
type and Carel supervisor address integer var. (read only) 36
Modbus address read register 136
resolution and unit of measure 1%
range 0 to 100
default --
Variable used to read the value measured by probe B2 expressed as a % of the range of measurement.
Range of measurement:
ratiometric pressure probes pressure interval specified by the manufacturer of the probe
Carel NTC temp. probe 10k
Ω temperature range defined by parameters T0L and T0H
Carel NTC temp. probe 50k
Ω temperature interval defined the parameters T1L and T1H
OUTV read/override output
type and Carel supervisor address integer var. 37
Modbus address read/write register 137
resolution and unit of measure 1%
range 0 to 100
default -
Variable used to read the output value and, if the Override function is enabled, to override it.
