FCP manual
Code +030220391 – rel 1.2 25/03/08
32
D12 to D14 12 to 14 0 0 1 not used
EOVR D15 15 0/1 0 1 Enable override output (NOTE 2) 0=disabled 1=enabled
FDEF D16 16 0/1 0 1 Reset default values (NOTE 3) 0=no action 1=enabled
STID D17 17 0/1 R 1 input ID1 status 0=open 1=closed
STD1 D18 18 0/1 R 1 dipswitch 1 status 0=Off 1=On
STD2 D19 19 0/1 R 1 dipswitch 2 status 0=Off 1=On
STD3 D20 20 0/1 R 1 dipswitch 3 status 0=Off 1=On
STD4 D21 21 0/1 R 1 dipswitch 4 status 0=Off 1=On
ALRM D22 22 0/1 R 1 alarm status 0=inactive 1=active
PB1A D23 23 0/1 R 1 probe B1 fault alarm 0=inactive 1=active
PB2A D24 24 0/1 R 1 probe B2 fault alarm 0=inactive 1=active
PB3A D25 25 0/1 R 1 probe B3 fault alarm 0=inactive 1=active
OKHZ D26 26 0/1 R 1 mains freq. reading 0=no ok 1=ok
STHZ D27 27 0/1 R 1 mains frequency 0=50Hz 1=60Hz
EEPA D28 28 0/1 R 1 parameter error alarm 0=inactive 1=active
D29 to D32 29 to 32 0 R 1 not used
Table 7.a
Key:
A = indicates analogue variables
I = indicates integer variables
D = indicates digital variables
R = indicates read only variables (no default values, as these are initialised/updated automatically at power-on)
NOTE 1:
The parameter should be modified via serial connection with care, as this implies the dynamic management of the address by the Master.
NOTE 2:
The override control is disabled at power-on and when serial communication is interrupted for more than 10 seconds.
NOTE 3:
The value is automatically set back to 0 when the function is activated.
