ir33 universale +030220801 - rel. 2.1 - 21.06.2011
d34 Output 1 activation restriction 0 0 4 - I 31 131 R/W 1
d35 Output 1 deactivation restriction 0 0 4 - I 32 132 R/W 1
d36 Minimum value for modulating output 1 0 0 100 % I 33 133 R/W 1
d37 Maximum value for modulating output 1 100 0 100 % I 34 134 R/W 1
F34 Output 1 cut-o
0=Cut-o operation
1=Minimum speed operation
0 0 1 - D 38 38 R/W 1
F35 Output 1 speed up duration
0= speed up disabled
0 0 120 s I 115 215 R/W 1
F36 Type of override for output 1
0= Disabled 3= minimum
1= OFF/0 Vdc 4= maximum
2= ON/10 Vdc 5= OFF respecting times
0 0 5 - I 116 216 R/W 1
c38 Output 2 dependence 1 0 29 - I 35 135 R/W 2
c39 Type of output 2 0 () 0 1 - D 30 30 R/W 2
c40 Output 2 activation -50 (
) -100 100 % I 36 136 R/W 2
c41 Output 2 di erential/logic 25 (
) -100 100 % I 37 137 R/W 2
d38 Output 2 activation restriction 0 0 4 - I 38 138 R/W 2
d39 Output 2 deactivation restriction 0 0 4 - I 39 139 R/W 2
d40 Minimum value for modulating output 2 0 0 100 % I 40 140 R/W 2
d41 Maximum value for modulating output 2 100 0 100 % I 41 141 R/W 2
F38 Output 2 cut-o
See F34
0 0 1 D 39 39 R/W 2
F39 Output 2 speed up duration
0= speed up disabled
0 0 120 s I 117 217 R/W 2
F40 Type of override for output 2
See F36
0 0 5 - I 118 218 R/W 2
c42 Output 3 dependence 1 0 29 - I 42 142 R/W 3
c43 Type of output 3 0 (
) 0 1 - D 31 31 R/W 3
c44 Output 3 activation -75 (
) -100 100 % I 43 143 R/W 3
c45 Output 3 di erential/logic 25 (
) -100 100 % I 44 144 R/W 3
d42 Output 3 activation restriction 0 0 4 - I 45 145 R/W 3
d43 Output 3 deactivation restriction 0 0 4 - I 46 146 R/W 3
d44 Minimum value for modulating output 3 0 0 100 % I 47 147 R/W 3
d45 Maximum value for modulating output 3 100 0 100 % I 48 148 R/W 3
F42 Output 3 cut-o
See F34
0 0 1 D 40 40 R/W 3
F43 Output 3 speed up duration
0= speed up disabled
0 0 120 s I 119 219 R/W 3
F44 Type of override for output 3
See F36
0 0 5 I 120 220 R/W 3
c46 Output 4 dependence 1 0 29 - I 49 149 R/W 4
c47 Type of output 4 0 (
) 0 1 - D 32 32 R/W 4
c48 Output 4 activation -100 (
) -100 100 % I 50 150 R/W 4
c49 Output 4 di erential/logic 25 (
) -100 100 % I 51 151 R/W 4
d46 Output 4 activation restriction 0 0 4 - I 52 152 R/W 4
d47 Output 4 deactivation restriction 0 0 4 - I 53 153 R/W 4
d48 Minimum value for modulating output 4 0 0 100 % I 54 154 R/W 4
d49 Maximum value for modulating output 4 100 0 100 % I 55 155 R/W 4
F46 Output 4 cut-o
See F34
0 0 1 D 41 41 R/W 4
F47 Output 4 speed up duration
0= speed up disabled
0 0 120 s I 121 221 R/W 4
F48 Type of override for output 4
See F36
0 0 5 I 122 222 R/W 4
c50 Lock keypad and remote control 1 0 2 - I 56 156 R/W
c51 Remote control enabling code
0= Programming from remote control without code
1 0 255 - I 57 157 R/W
c52 Display
0= Probe 1 4= Set point 1
1= Probe 2 5= Set point 2
2= Digital input 1 6= Probe 1 alternating with Probe 2
3= Digital input 2
0 0 6 - I 58 158 R/W
c53 Buzzer
0= Enabled
1= Disabled
0 0 1 - D 33 33 R/W
c56 Delay on power-up 0 0 255 s I 59 159 R/W
c57 Soft start circuit 1 0 0 99 min/°C I 60 160 R/W
d57 Soft start circuit 2 0 0 99 min/°C I 123 223 R/W
c62 ti_PID1 600 0 999 s I 61 161 R/W TUNING
c63 td_PID1 0 0 999 s I 62 162 R/W TUNING
d62 ti_PID2 600 0 999 s I 124 224 R/W TUNING
d63 td_PID2 0 0 999 s I 125 225 R/W TUNING
c64 Auto-Tuning
0= Disabled
1= Enabled
Validity: c19 ≠7
0 0 1 - D 34 34 R/W TUNING
c65 Logical enabling hysteresis 1,5 (2,7) 0 (0) 99,9 (179) °C (°F) A 34 34 R/W
c66 Start enabling interval
Validity: c0 = 1, 2
-50 (-58) -50 (-58) 150 (302) °C (°F) A 22 22 R/W
