56
ENG
ir33 universale +030220801 - rel. 2.1 - 21.06.2011
9.2 Cleaning the controller
When cleaning the controller do not use ethanol, hydrocarbons (petrol), ammonia and by-products. Use neutral detergents and water.
9.3 Product codes
IR33-DN33 UNIVERSAL
CODE
Description
Flush mount DIN rail mounting
In. temp. In. universal In. temp. In. universal
IR33V7HR20 IR33V9HR20 DN33V7HR20 DN33V9HR20 2AI, 2DI, 1DO, BUZ, IR, 115 to 230 V
IR33V7HB20 IR33V9HB20 DN33V7HB20 DN33V9HB20 2AI, 2DI, 1DO, BUZ, IR, RTC, 115 to 230 V
IR33V7LR20 IR33V9MR20
 DN33V7LR20 DN33V9MR20 2AI, 2DI, 1DO, BUZ, IR, 12 to 24 Vac, 12 to 30Vdc (= 24 Vac/Vdc)
IR33W7HR20 IR33W9HR20 DN33W7HR20 DN33W9HR20 2AI, 2DI, 2DO, BUZ, IR, 115 to 230V
IR33W7HB20 IR33W9HB20 DN33W7HB20 DN33W9HB20 2AI, 2DI, 2DO, BUZ, IR, RTC, 115 to 230V
IR33W7LR20 IR33W9MR20
 DN33W7LR20 DN33W9MR20 2AI, 2DI, 2DO, BUZ, IR, 12-24 Vac, 12 to 30 Vdc ( = 24 Vac/Vdc)
IR33Z7HR20 IR33Z9HR20 DN33Z7HR20 DN33Z9HR20 2AI, 2DI, 4DO, BUZ, IR, 115 to 230 V
IR33Z7HB20 IR33Z9HB20 DN33Z7HB20 DN33Z9HB20 2AI, 2DI, 4DO, BUZ, IR, RTC, 115 to 230 V
IR33Z7LR20 IR33Z9MR20
 DN33Z7LR20 DN33Z9MR20 2AI, 2DI, 4DO, BUZ, IR, 12 to 24Vac, 12 to 30Vdc ( = 24 Vac/Vdc)
IR33A7HR20 IR33A9HR20 DN33A7HR20 DN33A9HR20 2AI, 2DI, 4SSR, BUZ, IR, 115 to 230 V
IR33A7HB20 IR33A9HB20 DN33A7HB20 DN33A9HB20 2AI, 2DI, 4SSR, BUZ, IR, RTC, 115 to 230 V
IR33A7LR20 IR33A9MR20
 DN33A7LR20 DN33A9MR20 2AI, 2DI, 4SSR, BUZ, IR, 12 to 24Vac, 12 to 30Vdc ( = 24Vac/Vdc)
IR33B7HR20 IR33B9HR20 DN33B7HR20 DN33B9HR20 2AI, 2DI, 1DO+1AO, BUZ, IR, 115 to 230 V
IR33B7HB20 IR33B9HB20 DN33B7HB20 DN33B9HB20 2AI, 2DI, 1DO+1AO, BUZ, IR, RTC, 115 to 230 V
IR33B7LR20 IR33B9MR20
 DN33B7LR20 DN33B9MR20 2AI, 2DI, 1DO+1AO, BUZ, IR, 12 to 24 Vac, 12 to 30 Vdc ( = 24 Vac/Vdc)
IR33E7HR20 IR33E9HR20 DN33E7HR20 DN33E9HR20 2AI, 2DI, 2DO+2AO, BUZ, IR, 115 to 230 V
IR33E7HB20 IR33E9HB20 DN33E7HB20 DN33E9HB20 2AI, 2DI, 2DO+2AO, BUZ, IR, RTC, 115 to 230 V
IR33E7LR20 IR33E9MR20
 DN33E7LR20 DN33E9MR20 2AI, 2DI, 2DO+2AO, BUZ, IR, 12 to 24 Vac, 12 to 30Vdc ( = 24 Vac/Vdc)
IROPZKEY00 Programming key
IROPZKEYA0 Programming key with power supply
IROPZ48500 RS485 serial interface
IROPZ485S0 RS485 serial interface with automatic recognition of TxRx+ & TxRx-
IROPZSER30 RS485 serial card for DN33
CONV0/10A0 Analogue output module
CONV0NOFF0 ON/OFF output module
Tab. 9.b
AAI=analogue input; AO=analogue output; DI= digital input; DO=digital output, relay; BUZ=buzzer; IR=infrared receiver; RTC=Real Time Clock.
9.4 Conversion tables from IR32 universale
9.4.1 Panel mounting
Models Temperature inputs Universal inputs Description
ir33 ir32 ir33 ir32
1 Relay IR33V7HR20 IR32V0H000 IR33V9HR20 IR32V*H000 2AI, 2DI, 1DO, BUZ, IR, 115 to 230 Vac
IR33V7HB20 IR33V9HB20 2AI, 2DI, 1DO, BUZ, IR, RTC, 115 to 230 Vac
IR33V7LR20 IR32V0L000 IR33V9MR20
 IR32V*L000 2AI, 2DI, 1DO, BUZ, IR, 12 to 24 Vac 12 to 30 Vdc ( = 24 Vac/dc)
2 Relays IR33W7HR20 IR33W9HR20 2AI, 2DI, 2DO, BUZ, IR, 115 to 230 Vac
IR33W7HB20 IR33W9HB20 2AI, 2DI, 2DO, BUZ, IR, RTC, 115 to 230 Vac
IR33W7LR20 IR32W00000 IR33W9MR20 IR32W*0000 2AI, 2DI, 2DO, BUZ, IR, 12 to 24Vac 12 to 30Vdc ( = 24 Vac/dc)
4 Relays IR33Z7HR20 IR33Z9HR20 2AI, 2DI, 4DO, BUZ, IR, 115 to 230 Vac
IR33Z7HB20 IR33Z9HB20 2AI, 2DI, 4DO, BUZ, IR, RTC, 115 to 230 Vac
IR33Z7LR20 IR32Z00000 IR33Z9MR20
 IR32Z*0000 2AI, 2DI, 4DO, BUZ, IR, 12 to 24 Vac 12 to 30 Vdc ( = 24 Vac/dc)
4 SSR IR33A7HR20 IR33A9HR20 2AI, 2DI, 4SSR, BUZ, IR, 115 to 230 Vac
IR33A7HB20 IR33A9HB20 2AI, 2DI, 4SSR, BUZ, IR, RTC, 115 to 230 Vac
IR33A7LR20 IR32A00000
IR32D0L000
IR33A9MR20
 IR32A*0000
IR32D*L000
2AI, 2DI, 4SSR, BUZ, IR, 12 to 24Vac 12 to 30 Vdc ( = 24 Vac/dc)
1 Relay
+1 0-10 V
IR33B7HR20 IR33B9HR20 2AI, 2DI, 1DO+1AO, BUZ, IR, 115 to 230 Vac
IR33B7HB20 IR33B9HB20 2AI, 2DI, 1DO+1AO, BUZ, IR, RTC, 115 to 230 Vac
IR33B7LR20 IR32D0L000 +
1 CONV0/10A0
IR33B9MR20
 IR32D*L000 +
1 CONV0/10A0
2AI, 2DI, 1DO+1AO, BUZ, IR, 12 to 24 Vac 12 to 30Vdc ( = 24 Vac/dc)
Tab. 9.c
9.4.2 DIN rail mounting
Models Temperature inputs Universal inputs Description
ir33 ir32 ir33 ir32
1 Relay DN33V7HR20 IRDRV00000 DN33V9HR20 IRDRV*0000 2AI, 2DI, 1DO, BUZ, IR, 115 to 230 Vac
DN33V7HB20 DN33V9HB20 2AI, 2DI, 1DO, BUZ, IR, RTC, 115 to 230 Vac
DN33V7LR20 DN33V9MR20
 2AI, 2DI, 1DO, BUZ, IR, 12 to 24 Vac 12 to 30 Vdc ( = 24 Vac/dc)
2 Relays DN33W7HR20 IRDRW00000 DN33W9HR20 IRDRW*0000 2AI, 2DI, 2DO, BUZ, IR, 115 to 230 Vac
DN33W7HB20 DN33W9HB20 2AI, 2DI, 2DO, BUZ, IR, RTC, 115 to 230 Vac
DN33W7LR20 DN33W9MR20  2AI, 2DI, 2DO, BUZ, IR, 12 to 24Vac 12 to 30Vdc ( = 24Vac/dc)
4 Relays DN33Z7HR20 DN33Z9HR20 2AI, 2DI, 4DO, BUZ, IR, 115 to 230 Vac
DN33Z7HB20 DN33Z9HB20 2AI, 2DI, 4DO, BUZ, IR, RTC, 115 to 230 Vac
DN33Z7LR20 IRDRZ00000 DN33Z9MR20
 IRDRZ*0000 2AI, 2DI, 4DO, BUZ, IR, 12 to 24 Vac 12 to 30 Vdc ( = 24 Vac/dc)
4 SSR DN33A7HR20 DN33A9HR20 2AI, 2DI, 4SSR, BUZ, IR, 115 to 230 Vac
DN33A7HB20 DN33A9HB20 2AI, 2DI, 4SSR, BUZ, IR, RTC, 115 to 230 Vac
DN33A7LR20 IRDRA00000 DN33A9MR20
 IRDRA*0000 2AI, 2DI, 4SSR, BUZ, IR, 12 to 24 Vac 12 to 30 Vdc ( = 24 Vac/dc)
1 Relay
+1 0-10 V
DN33B7HR20 DN33B9HR20 2AI, 2DI, 1DO+1AO, BUZ, IR, 115 to 230 Vac
DN33B7HB20 DN33B9HB20 2AI, 2DI, 1DO+1AO, BUZ, IR, RTC, 115 to 230 Vac
DN33B7LR20 IRDRA00000 +
1 CONV0/10A0
DN33B9MR20
 IRDRA*0000 +
1 CONV0/10A0
2AI, 2DI, 1DO+1AO, BUZ, IR, 12 to 24 Vac 12 to 30 Vdc
( = 24 Vac/dc)
Tab. 9.d
(*) = 0, 1, 2, 3, 4 indicating the types of input in the ir32 range.
