Carel ir33+ User Manual

11
ENG
ir33plus +0300028EN rel. 1.1 - 05.05.2017
6 71 2 3 8 9 10 11 12
PROBES DI DI
LN
12 12
R1
R1
12 (2) A
12A 5FLA
30LRA
EN60730-1
UL 873
AUX
-10T60
250 V~
Ixxxxx0xxxx: 12 V~ 300 mA~ max, 12...18 Vdc 300 mA dc max
IxxxxxLxxxx: 12...24 V~ 300 mA~ max, 12...30 Vdc 300 mA dc max
tLAN
interface
SERIAL
and KEY
IxxxM(0,7) (0,L) (A,L) (0,2)xx
IxxxM(0,7) (L) (N,C) (0,2)xx senza/without R1
POWER
SUPPLY
Fig. 2.r
Thermostats with 1/2 relays: compressor, aux
SERIAL
and KE
Y
PROBES DI
9 10 11 12
12 1
L
N
R1
43 5 7 86
R2
AUX
R1 R2
12 (2) A
12A 5FLA
30LRA
EN60730-1
UL 873
5 (1) A
5A 1FLA
6LRA
LN
IxxxxxExxxx: 230 V~ 25 mA~ max
IxxxxxAxxxx: 115 V~ 50 mA~ max
-10T60
POWER
SUPPLY
250 V~
Corrente massima totale su terminale 5: 12 A
Maximum current on terminal 5: 12 A
IxxxS(0,7) (E,A) (V,Y) (0,1,2,3,5)xx
IxxxS(0,7) (E,A) (P,S) (0,1,2,3,5)xx senza/without R2
Fig. 2.s
2
PROBES DI
9 10 11 12
12 1
L
N
R1 R2
8 (4) A
8A 2FLA
12LRA
1 3 4 5 6 7 8
R1 R2
8 (4) A
8A 2FLA
12LRA
EN60730-1
UL 873
AUX
-10T60
POWER
SUPPLY
250 V~
IxxxS(0,7) (E,A) (A,L) (0,1,2,3,5)xx
IxxxS(0,7) (E,A) (N,C) (0,1,2,3,5)xx senza/without R2
Corrente massima totale su terminale 1: 12 A
Maximum current on terminal 1: 12 A
LN
IxxxxxExxxx: 230 V~ 25 mA~ max
IxxxxxAxxxx: 115 V~ 50 mA~ max
SERIAL
and KE
Y
Fig. 2.t
6 7
8 (4) A
8A 2FLA
12LRA
1 2 3 4 5 8 9 10 11 12
PROBES DI DI
LN
12 12
R1 R2
R1 R2
12 (2) A
12A 5FLA
30LRA
EN60730-1
UL 873
AUX
-10T60
POWER
SUPPLY
250 V~
Corrente massima totale su terminale 3: 12 A
Maximum current on terminal 3: 12 A
LN
115...230 V~ 50 mA~ max
tLAN
interface
SERIAL
and KEY
IxxxS(0,7) H (A,L) (0,2) xx
Fig. 2.u
2.4 Optional connections
ir33+
1
2
IROPZDSP00:
Opzione interfaccia display
IROPZ48500:
Interfaccia scheda
seriale RS485
IROPZKEY**:
Chiave di programmazione
Fig. 2.n
ir33+ wide/ easy wide
IROPZDSP00:
Opzione interfaccia display
Display interface option
IROPZ485S0:
Interfaccia scheda seriale
RS485 intelligente
Smart serial board
interface RS485
IROPZKEY**:
Chiave di programmazione
Programming key
Fig. 2.o
ir33+ small wide/ easy small wide
IROPZDSP00:
Opzione interfaccia display
Display interface option
IROPZ48500:
Interfaccia scheda seriale RS485
Serial board interface RS485
IROPZKEY**:
Chiave di programmazione
Programming key
Fig. 2.p
2.5 ir33+ wiring diagrams
Thermometers
11 12
PROBES DI
12 1
8 (4) A
8A 2FLA
12LRA
L
N
AUX
R1
R1
EN60730-1
UL 873
1 2 4
-10T60
POWER
SUPPLY
250 V~
LN
IxxxxxExxxx: 230 V~ 25 mA~ max
IxxxxxAxxxx: 115 V~ 50 mA~ max
IxxxMx0(N,C)xxx: 12 V~ 300 mA~ max, 12...18 Vdc 300 mA dc max
SERIAL
and KEY
IxxxM(0,7) (E,A,0) (N,C) (0,1,2,3,5)xx senza/without R1
IxxxM(0,7) (E,A) (A,L) (0,1,2,3,5)xx
Fig. 2.q

Carel ir33+ Specifications

General

Model	ir33+
Category	Controller
Storage Temperature	-20°C to +70°C
Dimensions	74 x 32 x 60 mm
Communication	RS485
Operating Temperature	-10°C to +60°C
Protection Rating	IP65
Power Consumption	5 VA max
Relative Humidity	10% to 90% non-condensing
Number of Relays	3
