35
C24 Valore massimo ammesso da St2
Descrizione: C24 determina il valore max. impostabile per St2.
Modalità di accesso:
tastiera
se C50=1 o 3: PRG + SEL per 5”, password 77
se C50=0, 2 e 4 il parametro è solo visibile
telecomando
se C50=4: premere “INIZIO”, tasti e
se C50=0, 1, 2 e 3 il parametro è solo visibile
Validità:
versione
tutti i modelli
modi
C0=6,7,8,9 e funzionamento
speciale (C33=1)
altri parametri
C19=2, 3 e 4 con C0 =1 o 2
Campo di variazione: tra un min. di C23 a un max. di 999
Valore preimpostato: NTC=90, Corr./Tens.=110,
PT100=600, TcJ/K=999
P25 SET Allarme di “Bassa”
Descrizione: P25 rappresenta, in valore assoluto, l’effetti-
vo valore di intervento dell’allarme di “Bassa”. P25 è con-
tinuamente confrontato con il valore rilevato dalla sonda. Il
parametro P28 rappresenta in minuti il “ritardo di attivazio-
ne allarme”; l’allarme di “Bassa” (Er5) si attiva solo se la
misura resta inferiore a P25 per un tempo superiore a
P28. Il valore di P25 è un valore assoluto: nel caso si vari il
punto di lavoro è necessario verificare che il nuovo inter-
vallo di funzionamento non giunga oltre i limiti di allarme.
Set point di allarme relativo: il parametro P27 può abilitare
la gestione di allarme con set point relativi.
Modalità di accesso:
tastiera
se C50=1 o 3: PRG per 5”
se C50=0, 2 e 4 il parametro è solo visibile
telecomando
se C50=0, 1 o 4: diretto premendo “INIZIO”,
e i tasti dedicati del telecomando
se C50=2, 3 il parametro è solo visibile
Validità:
versione
qualsiasi modello
modi
qualsiasi C0
altri parametri
Campo di variazione: tra un minimo di -99 a un massimo
pari al valore di P26
Valore preimpostato: versioni NTC -50, corrente -10,
tensione -60, TcJ/K -99
P26 SET Allarme di ALTA
Descrizione: P26, analogamente a P25, rappresenta in
valore assoluto l’effettivo valore di intervento dell’allarme
di “Alta”. P26 è continuamente confrontato con il valore
rilevato dalla sonda (e visualizzato a display).
Qualora quest’ultimo superi P26 per un tempo superiore
a P28, il controllo attiva Er4, l’allarme di “Alta”. Anche per
P26, come per P25, vale la raccomandazione di verificarne
il valore affinché non si attivino allarmi di “Alta” durante il
funzionamento normale. Set point di allarme relativo: il
parametro P27 può abilitare la gestione di allarme con set point
relativi.
C24, maximum value of St2
Description: C24 determines the maximum value of St2.
Access modes:
keyboard If C50=1 or 3: hold down PRG + SEL for
5”, password 77
If C50=0, 2 and 4 the parameter will be
only displayed
remote control If C50=4: press “ENABLE”, and
If C50=0, 1, 2 and 3 the parameter will be
only displayed
Validity:
version All models
modes C0=6,7,8,9 and special mode
of operation (C33=1)
other param.s C19=2, 3 and 4 with C0 =1 or 2
Operating range: from C23 (min.) to 999 (max.)
Factory-set value: NTC=90, Current/Voltage=110,
Pt100=600, thcJ/K=999
P25, low temperature set-point
Description: P25 is the absolute value that causes the
controller to respond to a low temperature condition. The
value given to P25 is constantly compared with the rea-
douts detected by the sensor. The low temperature alarm
(Er5) is detected only when the temperature value goes
below the P25 value for a time-interval longer than that
selected through P28. Should you modify the set-point,
remember to check the alarm limits. Relative alarm set-
point: to enable alarm management with relative set-
points use parameter P27.
Access modes:
keyboard If C50=1 or 3: hold down PRG for 5”
If C50=0, 2 and 4, the parameter will be
only displayed
remote control If C50=0, 1 or 4: direct access by pressing
“ENABLE” and the dedicated buttons on
the remote control
If C50=2, 3: you can only display the
parameter
Validity:
version Any model
modes Any value of C0
other param.s
Operating range: from -99 (min.) to P26 (max.)
Factory-set value: NTC -50, current -10, voltage -60,
TcJ/K -99
P26, high temperature set-point
Description: similarly to P25, P26 is the absolute value
that causes the controller to respond to a high temperatu-
re condition. The value given to P26 is constantly compa-
red with the readouts detected by the sensor (you can
read these values on the display). As soon as the sensor
measures a value higher than P26 for a time-interval lon-
ger than that set through P28, the controller will generate
the high temperature alarm (Er4). As P26 is an absolute
value, check its value so as to avoid “High” temperature
alarms during normal operation. Relative alarm set-point:
to enable alarm management with relative set-points use
parameter P27.
