Carel pCO

27
PRINT2 (PRINTER BRANCH)
+--------------------+ Mask for the cyclic print setting.
¦ PRINTER AL¦ If the cyclic print has been selected, within the
¦ ¦ loop the following mask will be selected too.
¦Cyclic Print ¦
¦Enabled? No¦
+--------------------+
PRINT3 (PRINTER BRANCH)
+--------------------+ Mask for cyclic print interval setting
¦ PRINTER AL¦ calculated in minutes.
¦Print Cycle ¦
¦Time ¦
¦ 000 min. ¦
+--------------------+
DIN (INPUTS/OUTPUTS BRANCH)
+--------------------+ This is the first mask of the Inputs/Outputs
¦Digital Inputs: AL¦ branch you can reach by pressing the "I/O" button.
¦C=Close O=Open ¦ By pressing the
and the buttons you can
¦1:CCC 4 :CCC ¦ move within the loop.
¦7:CCC 10:CCC ¦ Visualisation of the digital inputs condition.
+--------------------+
DOUT (INPUTS/OUTPUTS BRANCH)
+--------------------+ Visualisation of digital outputs condition from n.1
¦Digital Outputs : AL¦ to n.3.
¦1 Part. Valve : No¦
¦2 Fan : No¦
¦3 Energy Saving: No¦
+--------------------+
DOUT1 (INPUTS/OUTPUTS BRANCH)
+--------------------+ Visualisation of digital outputs condition from n.4
¦Digital Outputs : AL¦ to n.6.
¦4 Humidification: No¦
¦5 Part.Compr.1 : No¦
¦6 Part.Compr.2 : No¦
+--------------------+
DOUT2 (INPUTS/OUTPUTS BRANCH)
+--------------------+ Visualisation of digital outputs condition from n.7
¦Digital Outputs : AL¦ to n.8. Instead of compressors there may be: “Open
¦ ¦ Cooling Valve” or “Close Cooling Valve” according
¦7 Compressor 1 : No¦ to the settings effected.
¦8 Compressor 2 : No¦
+--------------------+
DOUT3 (INPUTS/OUTPUTS BRANCH)
+--------------------+ Visualisation of digital outputs condition from n.9
¦Digital Outputs : AL¦ to n.11. Instead of heaters there may be: “Open
¦9 Heater 1 : No¦ Heating Valve” or “Close Heating Valve” according
¦10 Heater 2 : No¦ to the settings effected.
¦11 General Al. : No¦
+--------------------+
AOUT (INPUTS/OUTPUTS BRANCH)
+--------------------+ Visualisation of analogue outputs condition:
¦Analogue Outputs: AL¦ Cooling Valve and Heating valve.
¦ ¦
¦Cooling Valve:000.0V¦
¦Heating Valve:000.0V¦
+--------------------+
DATA (CLOCK/TIME BANDS)
+--------------------+ This is the first mask of the “Time /Time-bands”
¦ Clock & Date AL¦ branch you can reach by pressing the "Clock”
button.
¦ ¦ By pressing the
and the buttons you can
¦Date Setting : ¦ move within the loop.
¦dd/mm/yy 00/00/0000¦ This mask allows date setting.
+--------------------+
ORA (CLOCK/TIME BANDS)
+--------------------+ Mask for the setting of the present time.
¦ Clock & Date AL¦
¦ ¦
¦Time Setting: ¦
¦hh:mm 00:00 ¦
+--------------------+
