Carel pCO2 Series

S&2ð
cod. Carel +030221826 rel. 2.0 dated 03/10/02
29
 6ROLGVWDWHUHOD\GLJLWDORXWSXWV665
The pCO² also features a version with solid state relays (SSR) for piloting devices which require an unlimited number of
switchings which would not be supported by electromechanical relays. They are dedicated to loads powered at 24Vac/Vdc with a
maximum power P
max
= 10W. Please see codes in $FFHVVRULHVDQGLQVWUXPHQWVFRGHV.

)LJ

,03257$17:$51,1*: the load of the SSR relay is powered at 24Vac/Vdc, thus all the other terminals in the group, from
1 to 6, must be powered at 24Vac/Vdc due to the absence of double insulation within the group. Therefore, terminals from 1 to 6
can be powered at 110÷230Vac using a safety transformer (Class II) for the power supply to the 24Vac/Vdc load of the SSR
relay (separation of power supply ).
YHUVLRQ DYDLODELOLW\RI665RXWSXWV VWDQGDUGRXWSXWUHIHUHQFH UHTXHVWHGRXWSXWUHIHUHQFHV
60$//
up to one output 7 ---
0(',80
up to one output (upon request, two outputs) 7 12
/$5*(
up to one output (upon request, two or three
outputs)
7 12 and/or 14
   7DE

 7DEOHVXPPDULVLQJWKHGLJLWDORXWSXWVDFFRUGLQJWRWKHDYDLODEOHYHUVLRQV
YHUVLRQ 12
FRQWDFWV
FKDQJHRYHU
FRQWDFWV
WRWDO
RXWSXWV
RXWSXWUHIHUHQFHZLWK665
VWDQGDUG
RXWSXWUHIHUHQFHVZLWK665
QRWDYDLODEOH\HW
60$//
7 1 8 7 ---
0(',80
10 3 13 7 12
/$5*(
13 5 18 7 12 and/or 14
 7DE
,03257$17:$51,1*: the groups which featureGRXEOHLQVXODWLRQ between them are:
RXWSXWV* JURXS
1, 2, 3, 4, 5, 6, 7 1
8 2
9, 10, 11, 12, 13 3
14, 15 4
16, 17, 18 5
7DE
* the main insulation is guaranteed between the output of one group.
