Carel pCO2 Series

S&2ð
cod. Carel +030221826 rel. 2.0 dated 03/10/02
37
 5HPRWHWHUPLQDOZLWKS/$1QHWZRUNDQGWHOHSKRQHW\SHFDEOH
Remote-installation requires the insertion of two ferrites - code 0907858AXX at the markings with the letter F in Fig. 5.5.1. Figs.
5.5.2 a and 5.5.2 b show respectively the ferrites to be installed the open and closed position. The ferrites are mounted on the
telephone connecting cable, on the pCO² side (see Fig. 5.5.2 c) and the other terminal side (see Fig. 5.5.2 d).
:$51,1*: the telephone cable must leave the pCO² perpendicularly.
on/off alarm enter
pCO Terminal
menu I/O set prog.
?
info
Graphic
5RRP
7HPS
on/off enteralarm
max 50 m
F
)LJ
)LJD )LJE

)LJF )LJG
