Carel pCO2 Series

S&2ð
cod. Carel +030221826 rel. 2.0 dated 03/10/02
39
 5HPRWHLQVWDOODWLRQRIWKHWHUPLQDOLQDS/$1QHWZRUNZLWK$:*VKLHOGHGFDEOHV
This remote installation is shown in Fig. 5.5.3.1. Power supply is independent from the shared terminal.
set prog.
enter
Terminal
on/off alarm enter
AC/DC
converter
P = 3VA
n
J14 and J15 on 2-3
pLAN - to next T-device
AWG20/22
2 twisted pair
+
-


)LJ
 S/$1QHWZRUNWHFKQLFDOVSHFLILFDWLRQV
The technical specifications of the pLAN network are summarised in the following table.
GHVFULSWLRQ FKDUDFWHULVWLFV
Communication standard RS485
baud-rate (kbit/s) 65,2
Protocol Multimaster (Carel proprietary control)
Maximum length of the network: 500 metres
 7DE
