6
+0500040RU - 1.2 - 07.06.2011
ENG
Connectors
Example of connector codes: PCO5CON***, see the following table for the description:
PCO5CON * * 0
0= screw
1= spring loaded
S
= small
M= medium
L= large
Z= extra large
2= medium with valve
driver
Display
Built-in PGD1 (132x64 pixels), with backlit keypad.
TECHNICAL SPECIFICATIONS
Physical speci cations
dimensions SMALL version installable on 13 DIN modules, 110 x 227.5 x 60 mm
MEDIUM, LARGE, EXTRALARGE and VALVE DRIVER versions installable on 18 DIN modules, 110 x 315 x 60 mm
version with ULTRACAP MODULE only installable on the 18 module models with built-in valve driver, 110 x 315 x 75
mm
assembly DIN rail
Plastic case
• fi tted on DIN rail as per DIN 43880 and IEC EN 50022;
• material: technopolymer;
• fl ame retardance: V2 (to UL94) and 850 °C (IEC 60695);
• ball pressure test: 125 °C;
• resistance to creeping current: 250 V;
• colour: grey RAL 7035;
Electrical speci cations
power supply Versions without built-in valve driver
24 Vac +10/-15% 50 to 60 Hz and 28 to 36 Vdc +10/-20%;
maximum current 45 VA/20 W
Versions with built-in valve driver with or without Ultracap module::
24 Vac +10/-15% 50 to 60 Hz;
maximum current: 80 VA/35 W (90VA / 40W when Ultracap is charging)
terminal block with male/female plug-in connectors, max voltage 250 Vac;
cable cross-sect: min. 0.5 mm
2
- max 2.5 mm
2
CPU H8SX1651, 32 bit, 44 MHz
memory (FLASH MEMORY) 4MB (8MB in the extended versions).
Further 32 MB NAND Flash memory also available.
data memory (static RAM) 512 kB at 16 bit s(296 kB Bios; 216 kB application)
parameter data memory 13 kB at 16 bit (max limit: 400,000 writes per memory location) plus 32 kB
E
2
PROM (not available in pLAN)
working cycle time (applications of avg. complexity) 0.2 s (typical)
clock with battery standard
clock precision 100 ppm
battery speci cations Lithium button battery, code CR2430, voltage 3 Vdc (dimensions 24x3 mm)
