Capturing or Viewing Images on a Monitor
1. Connect the camera to a monitor.
S-Video Connection
AV Connection
2. Repeatsteps1-3fromRecording or Viewing
Videos.
3. Pressthereviewbuttonfor3seconds.ThePatient
Numberdialogboxisdisplayed.
4. Pressthereviewbuttonstoassignanumbertothe
patient.
5. PresstheCapturebuttontoconrmtheselection.The
livevideomodeisdisplayed.
6. Havethepatientfullyopentheirmouth.
7. Holdthecameraovertheareaofinterest.
8. Press the Capture button on the camera to capture an
image.
9. Pressthereviewbuttonstoreviewonebyoneallthe
stored images.
10. Removeanddisposeoftheprotectivesheathwhen
youhavenishedwiththecurrentpatient.
Recording or Viewing Videos
1. Wipethelensofthecamerawithamoistlint-free
cloth or lens tissue.
2. Install a sheath on the camera.
3. Power the camera on.
4. StarttheKODAKDentalImagingSoftware.
IfusingimagingsoftwareviaTWAINinterface,see
CS1200UserandInstallationGuide.
5. Createoropenapatientrecord,ifapplicable.
6. InKODAKDentalImagingSoftware,click
and
selectyourcamera.
7. Havethepatientfullyopentheirmouth.
8. Holdthecameraovertheareaofinterest.Thevideo
imageappearsinthepreviewscreen.
9. Torecordthevideo,ontheAcquisitioninterface,click
to record and reclick to stop the recording.
10. Usethetoolbaroptionstoadjust,save,ordelete
recordedvideos.
11. Whenyouaredone,click toclosetheAcquisition
interface.
12. Removeanddisposeoftheprotectivesheath.
©CarestreamHealth,Inc.,2011.TheKodaktrademark
andtradedressareusedunderlicensefromKodak.
CarestreamDental
ADivisionofCarestreamHealth,Inc.
150VeronaSt.
Rochester,NY14608
USA
For more information, visit: www.carestreamdental.com
To give documentation feedback, visit:
www.carestreamdental.com/documentationfeedback
A
B
C
3 sec.
AC/DC
AC/DC
9H2304 Ed02 2011-08
1. PreviewScreen
2. Livevideobutton
3. Reviewbutton
4. Capture button
5. Videorecordbutton
6. Preference button
7. Exit button
1. ReviewScreen
2. ImageGallery
3. Reviewbutton
4. Toothchartcommentbutton
5. Select a format button
6. ImageProcessingDialogbox
7. Exit button
Acquisition Interface Overview
Live Video
Review Screen
7
1
2
3 4 5
6
1
2 3 4 5 6
7
Capturing or Viewing Images
1. Repeatsteps1-8fromRecording or Viewing
Videos.
2. Tocaptureanimage:Pressthecapturebuttononthe
camera.ORClick ontheAcquisitioninterface.
3. Usethetoolbaroptionstoadjust,save,ordelete
captured images.
4. Whenyouaredone,click toclosetheAcquisition
interface.
5. Removeanddisposeoftheprotectivesheath.
