Vedpak 223_Version 1_09.2019
211165
Multi-Function Automobile Tester
I. SPECIFICATION
• POWER SOURCE: 12-24V DC SYSTEM
• DC VOLTAGE MEASUREMENT RANGE: 0-70V
• DC CURRENT MEASUREMENT RANGE: 0-5A
• FREQUENCY MEASUREMENT RANGE: 0-300KHz (SQUARE WAVE)
• RESISTANCE MEASUREMENT RANGE: 0-200KΩ
• WORKING TEMPERATURE: 0-50°C
• STORAGE TEMPERATURE: -10-60°C
• WORKING HUMIDITY: ≤ 85%
• MEASURED TEMPERATURE RANGE: -50 – 500°C / -58-932°F
(ERROR will be displayed when tester is not connected with temperature probe.)
II. PRODUCT DESCRIPTION
Temperature
Measurement
Temp. Sensor
Testing Probe (4)
Thermocouple (13)
(OPTIONAL)
Testing Temp.
≤150°C / 302°F
≤500°C / 932°F
To Next Page
