8
Trigger:
Inputsusedastriggerofthetimer
Out:
Outputcontrolledbythetimer
Time:
Setthetime“t”.Thistimeisadjustablebetween0.1secondsand1week
8Set/ResetFlipflops(Flipflop0toFlipflop7)
Eachflipflophas4parameterstoadjust:Type,SET,RESETandOut
Type:
0–Flipflopdisabled
1–Flipflopenabled
SET:
Whenthisinputis activated(1)theoutputOUTisset1
RESET:
Whenthisinputisactivated(1)theou tputisresetto0.
Thisinputshas prioritysoif SETandRESET
areboth1,theoutputOUTwillbe0
Out:
Outputcontrolledbytheflipflop
t
t
t
t
t
Trigger
Out
