Hi-hat assembly
1. Unscrew the round and crescent metal parts in the
Hi-hat support head.
2. Rotate the crescent and round metal parts after
stepping on the support head through the
positioning hole.
Crescent metal parts
Round metal parts
Hi-hat stand assembly
1. Place hi-hat stand base directly beneath the frame mounting point.
2. Thread the metal rod through the frame mounting point and screw into the hi-hat
base rod, turning clockwise and fastening tightly.
3. Pass the hi-hat top post through the mounting point and lower the post into the
hi-hat base.
4. Set to your desired height, then lock into place with the wing nut on the hi-hat
base and the wing nut on the frame mounting point.
