Bass drum assembly
1. The bass drum tower stand is made from 3 parts.Connect the larger plates together using
the central connecting bracket found in the bass pad box.
The bracket is held in place with 2 drum bolts, fit and tighten these with your supplied drum
tool.
2.Attach the bass pad to the tower stand with
These bolts thread through the 3 holes at the top of the tower stand and then fasten into the
holes on the back of the bass pad.Tighten these bolts with your supplied drum tool.
the 3 bolts found on the back of the bass pad.
Central connecting bar
Drum bolts
4
