Carlyle 06DA824 User Manual

23
Figure 12A – Pressure Loaded Operation
Figure 13A – Pressure Unloaded Operation
(7.2)
(6.5)
(5.8)
(5.2)
(4.5)
(3.8)
(3.1)
(2.4)
(1.7)
(1.0)
LOAD — UP PRESSURE PSIG (BAR)
TURNS OUT FROM BOTTOM STOP — COUNTERCLOCKWISE
0123 45 678 9101112
90
80
70
60
50
40
30
20
10
0
DOTTED LINES INDICATE EXPECTED
TOLERANCE EXTREMES UNDER
NORMAL R-22 OPERATING CONDITIONS
150 PSI (10.4 BAR) SYSTEM DIFFERENTIAL
LOAD UP PRESSURE VS NO. OF TURNS
Figure 14 – Control Set Point -
Bypass & Suction Cut-Off
