27
COMPRESSOR MOTOR DATA
COMPRESSOR MAX.
MODEL* VOLT HP kW
MAX.
MUST
TRIP
AMPS
MAX.
RLA
RECOMMENDED
CIRCUIT
BREAKER
PART NO.
06ER(1/4)50100 575 38 27.1 96
(1/4)50600
400/460
15 22.0
46 32.9 142
(1/4)50300 208/230 90 64.3 283
LRA
XL
LRA PW
(1ST
WINDING)
CIRCUIT BREAKER DATA
MUST
HOLD
AMPS
MUST
TRIP
AMPS
LRA
RECOMM.
RLA
(1/4)50300
460 46 32.9 142
59
85
170
85
HH83XA460
HH83XA463
HH83XB626
HH83XA463
29
40
78
40
33.5
46
90
46
97
150
250
150
23.9
33.9
64.3
33.9
06ER(1/4)65100 575 45 32.1 120
(1/4)65600 400/460
20 25.3
54 38.6 173
(1/4)65300 208/230 108 77.1 345
(1/4)65300 460 54 38.6 173
72
104
207
104
HH83XA461
HH83XA424
HH83XB625
HH83XA424
33
42
91
42
38
49
104
49
124
175
350
175
27.1
35.0
74.3
35.0
06ER(1/4)75100 575 45 32.1 120
(1/4)75600 400/460
20 25.3
54 38.6 173
(1/4)75300 208/230 108 77.1 345
(1/4)75300 460 54 38.6 173
72
104
207
104
HH83XA461
HH83XA424
HH83XB625
HH83XA424
33
42
91
42
38
49
104
49
124
175
350
175
27.1
35.0
74.3
35.0
06ER(0/3)99100 575 65 46.4 176
(0/3)99600 400/460
30 39.1
84 60 253
(0/3)99300 208/230 168 120 506
(0/3)99300 460 84 60 253
106
152
304
152
HH83XA430
HH83XA478
HH83XC539
HH83XA478
50
65
142
65
58
76
163
76
168
274
507
274
41.4
54.3
116.4
54.3
Table 6 – Low Temperature - Across the Line Start
COMPRESSOR MOTOR DATA
COMPRESSOR MAX.
MODEL* VOLT HP kW
MAX.
MUST
TRIP
AMPS
MAX.
RLA
RECOMMENDED
CIRCUIT
BREAKER
PART NO.
06EM(1/4)50100 575 38 27.1 98
(1/4)50600
400/460
15 22.0
46 32.9 142
(1/4)50300 208/230 90 64.3 283
LRA
XL
LRA PW
(1ST
WINDING)
CIRCUIT BREAKER DATA
MUST
HOLD
AMPS
MUST
TRIP
AMPS
LRA
RECOMM.
RLA
(1/4)50300
460 46 32.9 142
59
85
170
85
HH83XA460
HH83XA463
HH83XB626
HH83XA463
29
40
78
40
33.5
46
90
46
97
150
250
150
23.9
33.9
64.3
33.9
06EA(2/5)65100 575 57 40.7 164
(2/5)65600 400/460
25 33.6
70 50 223
(2/5)65300 208/230 140 100 446
(2/5)65300 460 70 50 223
98
134
268
134
HH83XA469
HH83XA426
HH83XC509
HH83XA426
46
55
110
55
53
64
127
64
164
210
420
210
37.9
45.7
90.7
45.7
06EM(1/4)75100 575 57 40.7 164
(1/4)75600 400/460
25 33.6
70 50 223
(1/4)75300 208/230 140 100 446
(1/4)75300 460 70 50 223
98
134
268
134
HH83XA469
HH83XA426
HH83XC509
HH83XA426
46
55
110
55
53
64
127
64
164
210
420
210
37.9
45.7
90.7
45.7
06EM(1/4)99100 575 77 55 212
(1/4)99600 400/460
35 47.6
96 68.6 305
(1/4)99300 208/230 193 137.9 610
(1/4)99300 460 96 68.6 305
127
183
366
183
HH83XA453
HH83XA547
HH83XC532
HH83XA547
68
77
158
77
78
88
182
88
236
283
590
283
55.7
62.9
130.0
62.9
Table 7 – Medium Temperature - Across the Line Start
LEGEND
LRA — Locked Rotor Amps
MCC — Maximum Continuous Current
RLA — Rated Load Amps
*The last two digits of the compressors model number may vary. See page 4. The fifth digit in ( ) of the compressor model number represents models with or without
oil. 0, 1, 2 signifies older models with oil; 3, 4, 5 signifies newer models without oil. See page 4.
Max RLA = Max must trip amps ÷ 1.40
Recommended RLA = Circuit breaker must trip amps ÷ 1.40
