Carpigiani K 3 User’s guide
This manual is for the exclusive use of licensees and employees of McDonald’s Systems Inc Page 15 of 63
Version 5: October 2012
Machines equipped with “LONWORKS” device, Service Pin:
Activation of the service pin, proceed as follows:
1. Place one side of the machine in STOP
2. Press PROD
button for 10 seconds (a beep signal is activated)
At the end of the procedure put the side in standard function (Production or Storage)
AGITATION BUTTON (CLEANING)
By pressing this button from STOP, the led turns on and the display indicates:
KEY DISPLAY Comments
1
HOT=058 TEC+014
Beater + Pump ON
Pressing this button one time, the beater motor and the
mix pump motor will turn ON. HOT (consistency) and TEC
(cylinder’s temperature) are displayed in the first line.
2
HOT=058 TEC+014
Pump ON
Pressing this button for the second time we arrest the
beater motor but the mix pump remains on.
3
HOT=058 TEC+014
Beater ON
Pressing this button for the third time we activate the
beater motor and the mix pump motor stops.
4
HOT=058 TEC+014
Beater + Heating
Pressing this button for the fourth time we activate both the
beater motor and the mix pump motor and the heating as
well to help the product to melt.
Pressing Production again we return to first display.
LOCK BUTTON
To clean the keyboard panel with a clean towel it is recommended to block the keys of the
keyboard as follows:
Keep the
button pressed for 3 seconds, the respective led will flash indicating that
the keyboard is locked. At this point you can clean the keyboard safely. To restart it, just
keep the same key pressed for 3 seconds and the led will turn off.
