Carpigiani K 3 User’s guide
This manual is for the exclusive use of licensees and employees of McDonald’s Systems Inc Page 17 of 63
Version 5: October 2012
When the LCD back light is blinking, that means an alarm has tripped.
When it becomes still, the alarm which has previously tripped, has automatically reset and
the indication on the display must be reset by pressing RESET button
.
EVENTS
In order to read the events, the machine must be in STOP, so keep the pressed until ****READ
EVENTS**** is displayed.
02:00:00 06 APR
START PASTEUR
The first event will appear on the display. Push or in order to scroll UP or DOWN the events
list.
PUSH TO EXIT THE EVENTS READING AND GO TO STOP.
MILK SHAKE DISPENSING BUTTONS
Every “coloured cup” button corresponds to a milk shake flavour.
In PRODUCTION, the product is dispensed according to the flavour selected.
If, while dispensing milk shake, you push any “coloured cup” button, the milk shake will
immediately stop without reaching its automatic level; this function may be used to
dispense small portions. (tasting function).
When in STOP, by pushing the button
the piston opens and remains opened; by
pushing again it closes.
When in STOP, the “coloured cup” button are used for calibration of syrup quantity.
SYRUP QUANTITY CHECK AND SYRUP SYSTEM CLEANING
While the machine is in STOP:
- Push one time only the “coloured cup” button.
- Syrup will be dispensed for 5/7 seconds.
- Check the quantity of the syrup using the calibration cup.
- If the quantity of syrup is not satisfactory then modify the calibration as explained in
the manager menu.
- By pushing a second time while the syrup pump is ON, the pump will run at MAX
speed in order to flush and clean the syrup tubes.
