Carpigiani K 3 User’s guide
This manual is for the exclusive use of licensees and employees of McDonald’s Systems Inc Page 19 of 63
Version 5: October 2012
2.1.2 SUNDAE FUNCTIONS
STOP BUTTON
By pressing this push-button during operation, the machine stops (LED on).
DISPLAY Comments
10:33:21 Fri
When the machine is in STOP, the display shows Time and Date.
PRODUCTION BUTTON
Press PROD button to start the production mode (LED on). The motor and compressor are
automatically controlled by HARD-O-TRONIC system.
By pressing this button from STOP, the display indicates:
KEY DISPLAY comments
1
Do Not Serve!
TEV +19°C W -14
When the sundae is not ready, the display shows: “DO
NOT SERVE“
Sundae Ready!
TEV +19°C W -14
When the sundae has reached the desired consistency the
display shows “SUNDAE READY”.
Do Not Serve!
Beater HT Sensor
In case of ALARM, this will be displayed in the second row
2
Hopper +14°C
Cylinder +13°C
In this box the display shows the Hopper’s temperature in
the first line (above) and the Cylinder’s temperature in the
second one.
3
In this box the display shows in the first line (above):
Set=100: set HOT SOFT
HOT=085: the consistency actually detected in the soft
cylinder.
4
Cones today
12345
In this box the display shows the daily quantity of cones
(starting from 0:00 until 23:59).
5
Total Cones
0923456780
In this box the display shows the total quantity of cones.
6
TEV+010 TGV-022
TEC+013 TE1-012
In this box the display shows various probes of the SHAKE
part ( no °C nor °F are displayed).
7
Topping +057
Set Topping +055
In this box the display shows the Topping probe ( no °C
nor °F are displayed), with the respective temperature sets.
Pushing PROD again, we return to the initial display.
Set=100 Hot=085
