10
TECHNICAL DATA
Input Voltage AC 220-240VAC, 50/60Hz
Output Voltage 6V & 12V (Manual-select)
Input Current 0.4A RMS max
Efficiency >75%
Charging Voltage
Normal temperature mode
Maintenance charging mode
Recovery mode
7.2V±0.125V (for 6V), 14.4V±0.25V (for 12V)
6.8V±0.125V (for 6V), 13.6V±0.25V (for 12V)
8V (for 6V battery), 16V (for 12V battery)
Charging Current 1.0A±0.1A or 0.6A±0.1A or 0.2A±0.05A or 0.2A ON 30
min and OFF 30 min, 0.1A±0.05A
Back Current Drain* <5mA
Ripple** Max 150mV, 0.3A
Ambient Temperature -20°C to +50°C/-4°F to +122°F, Reduced output power at
higher temperature
Type of Charger Five step, fully automatic, switch mode with maintenance
charging
Type of Batteries 6V & 12V Lead-acid batteries (WET, MF,AGM and GEL)
Battery Capacity 1.2-12Ah (for 6V), 7.2-60Ah (for 12V)
Dimensions (LxWxH) 140x60x34.5mm
Housing Protection IP65 (Dust and Splash proof) Indoor use
Weight 0.38kg
Noise Level <50 dB (Tested from a distance of 50cm)
* Back current drain is the amount of current drawn by the charger from battery, when the charger is
connected to the battery, without power cord connected. Carpoint charger has extremely low back current
drain which corresponds to 0.7 Ah per month (1mA/hr)
** Ripple refers to interference of current and voltage. A high current ripple heats up battery and reduces life
of battery. Against a linear charger, which has a current ripple of up to 400%, Carpoint charger’s current
ripple is below 2.5% (0.15/6V or 0.3/12V battery voltage) ,which is much lower than the max 5% for a
sealed acid battery. Equipments connected to the battery could be damaged by high voltage ripple.
ENGLISH
