short-circuiting.
• Disconnectthebatteryfromthechargerwhenchargerisnotconnectedtothepowersupply.
This will reduce back drain current.
• Chargingmustbeceasedimmediatelyifbatteryisfoundtobetoohotorleaksoutliquid
during charging.
• Incaseofmalfunctionordamage,immediatelydisconnectthechargerfromthemains.
• Donotusevehiclewhenchargingpermanentlyinstalledbatteries.
• Ensurethatchargerswitchestomaintenancechargemode,beforeitisleftunattendedand
connected for long time. If this stage does not arrive within 73 hours (max), the charger must
be disconnected manually.
LOCATE CHARGER
• LocatethechargerasfarawayfrombatteryastheDCcordpermits.
• Whilechargingdonotplacechargerdirectlyaboveorbelowthebattery.Gasesoruidsfrom
the battery may corrode and damage the charger.
• Neverallowbatteryacidtodriponthecharger.
• Chargingshouldbecarriedoutinawell-ventilated,weatherprotectedfacility.
BATTERY TYPE & SETTINGS
The following recommendations should only be referred to as guidelines. For precise details, you
must refer to battery manufacturer for instructions.
Symbol Mode Settings Details
1 7.2V/1.0A This mode is normally suitable for 6V (1.2Ah to
12Ah) WET/Flooded, GEL, AGM, MF, VRLA type
lead-acid rechargeable batteries.
2 14.4V/1.0A This mode is normally suitable for 12V (7.2Ah to
60Ah) WET/Flooded, GEL, AGM, MF, VRLA type
lead-acid rechargeable batteries.
CHARGING
1) Charging of a permanently installed battery in a vehicle
a) Before connecting or disconnecting the battery leads, the power cord should be removed
from the mains.
