The Carrera No. 624 Hair/Beard Clipper is a versatile grooming tool designed for trimming facial and head hair, suitable for residential, commercial, and industrial use. It is engineered in Germany with a focus on user-friendliness, handling, aesthetics, and performance.

Function Description:

The hair clipper features a cutting unit and a precision trimmer, allowing for various hair lengths and precise styling. It comes with two main attachments: a precision attachment for beards and short hair, and a comb attachment for longer hair. The precision attachment allows for length adjustments from 1 to 11 mm in 1 mm increments, while the comb attachment offers lengths from 12 to 33 mm in 3 mm increments. An ON/OFF button controls the device, and a transport lock feature prevents accidental activation. The device operates cordless, powered by a rechargeable Li-ion battery.

Important Technical Specifications:

Input: 5 V, 1 A
Battery: Li-ion, 800 mAh, 3.7 V
Operating Temperature: -10 to +40 °C
Protection Type: IPX6
Protection Class: III
Cordless Use Time: Approximately 60 minutes on a full charge.
Charging Time: 90 minutes for a full charge.

Usage Features:

Before first use, the appliance should be charged for 90 minutes. The display shows the battery level in percent (01-100%), along with battery and plug symbols. A red flashing plug symbol indicates a nearly drained battery. For optimal battery life, regular use and full discharge before recharging are recommended.

To use, ensure the appliance is charged and an appropriate attachment is installed. The ON/OFF button activates the clipper. A transport lock can be engaged or disengaged by pressing and holding the ON/OFF button for approximately 3 seconds. The lock symbol will flash briefly before going out.

For beard trimming, install the precision attachment and set the desired length using the adjustment wheel. Trim the beard with smooth movements, moving from the ears to the chin, and the mustache from the nose to the corners of the lips. For the neck, either remove the attachment or set it to a short length for a clean line.

For hair trimming, choose between the precision or comb attachment based on desired hair length. Start with a longer setting and adjust as needed. Begin cutting from the bottom of the back of the head, moving towards the temples against hair growth. Avoid cutting too fast or making jerky movements, allowing the attachment to lightly touch the head. Clean the attachment from cut hair as you work. For contouring the neck and sideburns, remove the attachment and gently move the clipper against hair growth.

For edging, the cutting block or precision trimmer (by pressing button 3) can be used.

Maintenance Features:

Regular cleaning is crucial for extending the appliance's lifespan. A built-in timer reminds users to clean the appliance after 30 minutes of trimming by flashing the cleaning symbol on the display. If the appliance is switched off while the cleaning symbol is flashing, the timer resets.

To clean:

Turn off the appliance, disconnect the USB cable, and remove the attachment.
Remove the cutting block and rinse it under running water. Use the double-sided cleaning brush (17) to clean the cutting unit installation slot. Thoroughly dry the cutting unit before reinstalling.
Use the brush to clean the precision trimmer.
Wash attachments under running water, using a mild detergent if necessary, and dry thoroughly before reuse.
After cleaning, oil the blades with blade oil (18) or any acid-free oil (e.g., sewing machine oil) to ensure complete functionality. Apply one or two drops between the blades, distribute evenly, and wipe off any excess.
Store the appliance in a dark, cool place out of children's reach, ensuring the USB cable is not tangled.

Safety Instructions:

Always connect the USB cable to the appliance first, then to the power adapter and outlet.
Ensure mains voltage matches the power adapter.
Do not use the appliance in outdoor environments, near hot surfaces, open flames, or where aerosols or flammable liquids are present.
The appliance is designed for dry hair only. Do not use on open wounds, cuts, sunburn, or blisters.
Disconnect from the USB cable before cleaning in water.
Do not use while bathing or near water-filled vessels. If it falls into water, immediately remove the USB cable from the power supply before reaching into the water.
Never immerse the appliance or charging cable in water or any liquids.
Do not touch the USB cable with moist or wet hands.
Do not cover the appliance, USB cable, or adapter during use or charging.
Do not leave the working appliance unattended.
Do not use for trimming animal hair.
Keep blade oil out of reach of children and avoid ingestion or eye contact.
Children over 8 and persons with reduced physical, sensory, or mental capabilities may use the appliance under supervision and with proper instruction.
Do not attempt to repair the appliance or modify its design; repairs should only be performed by a specialized service center.
The battery can only be replaced by a qualified specialist.
