Carrier 024-048 - Page 32

: Service Manual
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
32
Fig. 31 – Control Box Wiring
A08407
Fig. 32 – Unit Electrical Connection
Electric Heat wiring
interconnection (electric
heater controls removed
for clarity)
Electric Heat Control Box
(shown uninstalled)
Electric Heat wiring
interconnection (electric
heater controls removed
for clarity)
Electric Heat Control Box
(shown uninstalled)
Air Conditioning Control Box Wiring
Heat Pump Control Box Wiring
A10030
A10031
HIGH-VOLTAGE POWER
WIRING ENTRY HOLE
LOW-VOLTAGE WIRING
ENTRY HOLE
(grommet hole)
