Carrier 05G TWIN PORT User Manual

1--2
62--11052
1
2
3
4
67
10
8
11
9
COMPRESSOR WITH
MOUNTING FLANGE
(ULTRA TYPE SHOWN)
1 2
3
4
6
7
8
9
10
11
1. Discharge Service Valve
2. High Pressure Connection
3. Low Pressure Connection
4. Suction Service Valve
5. Guage Connection
6. Oil Fill Plug
7. Oil Level Sight Glass
8. Bottom Plate
9. Oil Drain Plug
10. Oil Pump (See Figure 1-3)
11. Unloader
12. Shaft Seal Reservoir
12
12
5
5
5
5
COMPRESSOR WITHOUT
MOUNTING FLANGE
Figure 1-1. Model 05G Compressor
