13
COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
Series
Indoor Model To tal C a p. B T U H
Factory Supplied
Enhancement
SEER
EER Furnace Model
Standard
Rating
TDR†
60---30
CAP**6021A** 58,000 TXV 14.00 11.50
CAP**6021A** 55,000 TDR&TXV 14.20 11.50 58MVB080---20
*CAP**6024A** 59,000 TXV 14.00 11.5
CAP**6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CAP**6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155---22
CNPV*6024A** 58,500 TXV 14.00 11.50
CNPV*6024A** 55,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPV*6024A** 57,500 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CNPV*6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155---22
CNPH*6024A** 58,500 TXV 14.00 11.50
CNPH*6024A** 55,500 TDR&TXV 14.20 11.50 58MVB080---20
CNPH*6024A** 55,500 TDR&TXV 14.50 12.00 58MVB100---20
CNPH*6024A** 55,500 TDR&TXV 14.50 12.00 58MVB120---20
CNPH*6024A** 57,500 TDR&TXV 14.20 11.50 58CV(A,X)110 ---20
CNPH*6024A** 57,500 TDR&TXV 14.50 12.00 58CV(A,X)135 ---22
CNPH*6024A** 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155 ---22
CSPH*6012A* * 59,000 TXV 14.00 11.50
CSPH*6012A* * 56,000 TDR&TXV 14.20 11.50 58MVB080---20
CSPH*6012A* * 56,000 TDR&TXV 14.50 12.00 58MVB100---20
CSPH*6012A* * 56,000 TDR&TXV 14.50 12.00 58MVB120---20
CSPH*6012A* * 58,000 TDR&TXV 14.20 11.50 58CV(A,X)110---20
CSPH*6012A* * 58,000 TDR&TXV 14.50 12.00 58CV(A,X)135---22
CSPH*6012A* * 58,000 TDR&TXV 14.50 12.00 58CV(A,X)155---22
FY4ANB060 59,000 TDR&TXV 13.50 11.20
FX4CN(B,F)060 59,500 TDR&TXV 14.00 11.50
FV4BNB006 59,000 TDR&TXV 14.50 12.00
* Tested combination
{ In most cases, only 1 method should be u sed to achieve TDR function. Using more than 1 method in a system may cause degradation in performance. Use
either the accessory Time---Delay Relay KAAT D0101TDR or a furnace equipped with TDR. Most Carrier furnaces are e quipped with TDR.
EER — Energy Efficiency Ratio
SEER — Seasonal Energy Efficiency Ratio
TDR — T i m e --- D e la y R e la y
TXV — Thermostatic Expansion Valve
NOTES:
1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air con ditione rs. Ratings for other
combinations are determined under DOE computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Do not apply with capillary tube coils as performance and reliability are significantly affected.
24ABA424ABA4
