14
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
Capacity
MBtuh†
To t a l
System
KW**
To t a l
Sens
‡
To t a l
Sens
‡
To t a l
Sens
‡
To t a l
Sens
‡
To t a l
Sens
‡
To t a l
Sens
‡
24ABA418A30 Outdoor Section With CAP**2414A** Indoor Section
525
72 21.57 11.21 1.17 20.52 10.80 1.32 19.45 10.39 1.49 18.33 9.97 1.67 17.18 9.55 1.88 15.93 9.09 2.11
67 19.60 13.63 1.18 18.65 13.23 1.33 17.67 12.81 1.50 16.65 12.40 1.69 15.60 11.96 1.90 14.46 11.51 2.13
62 17.82 16.04 1.19 16.96 15.63 1.34 16.08 15.22 1.51 15.18 14.79 1.70 14.29 14.29 1.91 13.44 13.44 2.13
57 17.16 17.16 1.20 16.49 16.49 1.35 15.79 15.79 1.51 15.06 15.06 1.70 14.29 14.29 1.91 13.44 13.44 2.13
600
72 22.01 11.78 1.19 20.92 11.37 1.34 19.79 10.95 1.51 18.62 10.52 1.70 17.42 10.09 1.91 16.12 9.62 2.14
67 20.03 14.54 1.21 19.03 14.13 1.36 18.00 13.71 1.53 16.94 13.28 1.71 15.84 12.84 1.92 14.66 12.37 2.15
62 18.27 17.29 1.22 17.38 16.86 1.37 16.50 16.41 1.54 15.70 15.70 1.72 14.86 14.86 1.93 13.95 13.95 2.16
57 17.96 17.96 1.22 17.23 17.23 1.37 16.48 16.48 1.54 15.70 15.70 1.72 14.87 14.87 1.93 13.95 13.95 2.16
675
72 22.34 12.32 1.22 21.20 11.90 1.37 20.03 11.47 1.54 18.83 11.04 1.72 17.58 10.60 1.93 16.24 10.13 2.16
67 20.35 15.42 1.23 19.31 15.00 1.38 18.25 14.57 1.55 17.15 14.13 1.74 16.02 13.68 1.95 14.80 13.21 2.18
62 18.68 18.46 1.24 17.86 17.86 1.39 17.06 17.06 1.56 16.22 16.22 1.75 15.33 15.33 1.95 14.37 14.37 2.18
57 18.63 18.63 1.24 17.86 17.86 1.39 17.06 17.06 1.56 16.22 16.22 1.75 15.33 15.33 1.95 14.37 14.37 2.18
Multipliers for determining the performance with other indoor sections.
Cooling
Indoor Model
Capacity Power Furnace Model
*CAP**2414A** 1.00 1.00
CAP**1814A** 0.99 1.02
CAP**2417A** 1.00 1.00
CNPF*2418A** 1.00 1.03
CNPH*2417A** 1.00 1.03
CNPV*1814A** 0.99 1.02
CNPV*2414A** 1.00 1.00
CNPV*2417A** 1.00 1.03
CSPH*2412A* * 1.00 1.00
FF1ENP018 0.99 1.02
FF1ENP024 1.00 1.03
FV4BNF002 1.01 0.88
FX4CNF018 1.00 0.88
FX4CNF024 1.02 0.90
FY4ANF018 0.99 1.02
FY4ANF024 0.99 1.02
CAP**1814A** 0.98 0.90 58CV(A,X)070---12
CAP**2414A** 0.99 0.88 58CV(A,X)070---12
CNPH*2417A** 0.99 0.88 58CV(A,X)070---12
CNPV*1814A** 0.98 0.90 58CV(A,X)070---12
CNPV*2414A** 0.99 0.88 58CV(A,X)070---12
CSPH*2412A* * 0.99 0.88 58CV(A,X)070---12
CAP**2417A** 0.99 0.88 58CV(A,X)090---16
CNPH*2417A** 0.99 0.88 58CV(A,X)090---16
CNPV*2417A** 0.99 0.88 58CV(A,X)090---16
CSPH*2412A* * 0.99 0.88 58CV(A,X)090---16
CNPH*2417A** 0.99 0.88 58MVB040---14
CSPH*2412A* * 0.99 0.88 58MVB040---14
CAP**2417A** 0.99 0.88 58MVB060---14
CNPH*2417A** 0.99 0.88 58MVB060---14
CNPV*2417A** 0.99 0.88 58MVB060---14
CSPH*2412A* * 0.99 0.88 58MVB060---14
CNPH*2417A** 0.99 0.88 58MVB080---14
CSPH*2412A* * 0.99 0.88 58MVB080---14
See notes on pg. 20
24ABA4
