COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
voltage,
Serie
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace ModelFactory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
ECOP
H
Capacity
HCOP
42---30, 50,
60
CSRH*4212A* * 41,000 TDR&TXV 13.50 11.20 41,000 3.58 25,600 2.54 8.0 58MVB060---14
CSRH*4212A* * 40,500 TDR&TXV 13.50 11.20 41,000 3.54 25,600 2.50 7.9 58MVB080---14
CSRH*4212A* * 41,000 TDR&TXV 13.50 11.20 41,000 3.58 25,600 2.54 8.0 58MVB080---20
CSRH*4212A* * 41,000 TDR&TXV 13.50 11.20 41,000 3.60 25,600 2.54 8.0 58MVB100---20
CSRH*4212A* * 41,000 TDR&TXV 13.50 11.20 41,000 3.60 25,400 2.54 8.0 58MVB120---20
CSRH*4212A* * 41,000 TDR&TXV 13.50 11.20 41,000 3.56 25,600 2.52 7.9 58CV(A,X)070---12
CSRH*4212A* * 41,000 TDR&TXV 13.50 11.20 41,000 3.62 25,400 2.56 8.0 58CV(A,X)090---16
CSRH*4212A* * 41,000 TDR&TXV 13.50 11.20 41,000 3.62 25,400 2.56 8.0 58CV(A,X)110---20
CSRH*4212A* * 41,000 TDR&TXV 14.00 11.50 41,000 3.66 25,400 2.58 8.1 58CV(A,X)135---22
CSRH*4212A* * 41,000 TDR&TXV 14.00 11.50 41,000 3.64 25,200 2.58 8.1 58CV(A,X)155---22
CSRH*4812A* * 42,500 TXV 13.00 10.80 42,500 3.62 26,600 2.50 8.0
CSRH*4812A* * 42,000 TDR&TXV 13.50 11.20 41,500 3.56 25,600 2.52 7.9 58MVB040---14
CSRH*4812A* * 42,000 TDR&TXV 13.50 11.20 41,500 3.60 25,600 2.54 8.0 58MVB060---14
CSRH*4812A* * 42,000 TDR&TXV 13.50 11.20 41,500 3.56 25,600 2.52 7.9 58MVB080---14
CSRH*4812A* * 42,000 TDR&TXV 13.50 11.20 41,500 3.60 25,600 2.54 8.0 58MVB080---20
CSRH*4812A* * 42,000 TDR&TXV 13.50 11.20 41,500 3.62 25,600 2.56 8.0 58MVB100---20
CSRH*4812A* * 42,000 TDR&TXV 13.50 11.20 41,000 3.62 25,400 2.56 8.0 58MVB120---20
CSRH*4812A* * 42,000 TDR&TXV 13.50 11.20 41,500 3.58 25,800 2.52 7.9 58CV(A,X)070---12
CSRH*4812A* * 42,000 TDR&TXV 13.50 11.20 41,500 3.64 25,400 2.56 8.1 58CV(A,X)090---16
CSRH*4812A* * 42,000 TDR&TXV 13.50 11.20 41,500 3.64 25,400 2.56 8.1 58CV(A,X)110---20
CSRH*4812A* * 42,000 TDR&TXV 14.00 11.50 41,000 3.68 25,400 2.58 8.1 58CV(A,X)135---22
CSRH*4812A* * 42,000 TDR&TXV 14.00 11.50 41,000 3.68 25,400 2.58 8.1 58CV(A,X)155---22
48---30, 50,
60
*FC4DN(F,B)048 46,500 TDR&TXV 13.00 11.00 48,000 3.40 30,000 2.54 8.4
FC4DN(F,B)048 46,500 TDR&TXV 13.20 11.00 48,500 3.40 30,000 2.54 8.4
FC4DN(F,B)060 47,500 TDR&TXV 13.50 11.20 48,500 3.48 29,800 2.60 8.6
FK4DNF005 46,000 TDR&TXV 13.50 11.20 47,500 3.30 29,400 2.52 8.2
FK4DNB006 47,000 TDR&TXV 14.00 11.50 47,500 3.42 29,400 2.58 8.4
CAR**4817A** 43,500 TDR&TXV 13.00 10.80 46,500 3.24 29,800 2.46 8.1 58CV(A,X)090---16
CAR**4821A** 44,500 TDR&TXV 13.00 10.80 47,500 3.18 29,800 2.44 8.0 58MVB080---20
CAR**4821A** 44,500 TDR&TXV 13.00 10.80 47,500 3.20 29,600 2.46 8.0 58MVB100---20
CAR**4821A** 44,500 TDR&TXV 13.00 10.80 47,500 3.22 29,600 2.46 8.0 58CV(A,X)110---20
CAR**4824A** 44,500 TDR&TXV 13.00 10.80 47,500 3.20 29,600 2.46 8.0 58MVB120---20
CAR**4824A** 45,000 TDR&TXV 13.20 11.00 47,500 3.24 29,400 2.50 8.1 58CV(A,X)135---22
CAR**4824A** 45,000 TDR&TXV 13.20 11.00 47,500 3.26 29,400 2.50 8.1 58CV(A,X)155---22
CAR**6021A** 45,500 TDR&TXV 13.20 11.00 48,000 3.22 29,800 2.48 8.1 58MVB080---20
CAR**6021A** 46,000 TDR&TXV 13.20 11.00 48,000 3.34 29,600 2.50 8.2 58MVB100---20
CAR**6021A** 46,000 TDR&TXV 13.50 11.20 47,500 3.26 29,600 2.52 8.2 58CV(A,X)110---20
CAR**6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.22 29,600 2.48 8.1 58MVB120---20
CAR**6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.28 29,400 2.52 8.2 58CV(A,X)135---22
CAR**6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.30 29,400 2.54 8.2 58CV(A,X)155---22
CNRV*4821A** 44,500 TDR&TXV 13.00 10.80 47,500 3.18 29,800 2.44 8.0 58MVB080 ---20
CNRV*4821A** 44,500 TDR&TXV 13.20 10.80 47,500 3.20 31,000 2.96 8.5 58MVB100 ---20
CNRV*4821A** 44,500 TDR&TXV 13.20 11.00 47,500 3.22 30,800 2.98 8.6 58CV(A,X)110---20
CNRV*4824A** 44,500 TDR&TXV 13.00 10.80 47,500 3.20 31,000 2.96 8.5 58MVB120 ---20
CNRV*4824A** 45,000 TDR&TXV 13.20 11.00 47,500 3.24 30,800 3.02 8.6 58CV(A,X)135---22
CNRV*4824A** 45,000 TDR&TXV 13.50 11.20 47,500 3.28 30,600 3.04 8.7 58CV(A,X)155---22
CNRV*6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.22 29,600 2.48 8.1 58MVB120 ---20
CNRV*6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.28 29,400 2.52 8.2 58CV(A,X)135---22
CNRV*6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.30 29,400 2.54 8.2 58CV(A,X)155---22
CNRH*4821A** 44,500 TDR&TXV 13.00 10.80 47,500 3.18 31,000 2.94 8.5 58MVB080---20
CNRH*4821A** 44,500 TDR&TXV 13.00 10.80 47,500 3.20 31,000 2.96 8.5 58MVB100---20
CNRH*4821A** 44,500 TDR&TXV 13.00 10.80 47,500 3.20 31,000 2.96 8.5 58MVB120---20
CNRH*4821A** 45,000 TDR&TXV 13.00 10.80 47,500 3.20 31,000 2.96 8.5 58CV(A,X)090---16
CNRH*4821A** 45,000 TDR&TXV 13.20 11.00 47,500 3.22 30,800 2.98 8.6 58CV(A,X)110---20
CNRH*4821A** 45,000 TDR&TXV 13.20 11.00 47,500 3.24 30,800 3.02 8.6 58CV(A,X)135---22
CNRH*4821A** 45,000 TDR&TXV 13.50 11.20 47,500 3.28 30,600 3.04 8.7 58CV(A,X)155---22
See notes on pg. 17
25HBR3

Carrier 25HBR3 Specifications

Electrical Requirements

nominal unit electrical characteristics (single phase)	v, single phase, 60 hz
nominal unit electrical characteristics (three phase)	v, three phase, 60 hz
control circuit voltage	24v

Fan Specifications

condenser fan type	direct-drive propeller type
condenser fan motor type	totally enclosed, 1-phase type
fan blade balance	statically and dynamically balanced
