14
DETAILED COOLING CAPACITIES
#
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Tot a l Sens‡ Total Sens‡
25HCD318(A,W)**30 Outdoor Section With FB4CNF018 Indoor Section
525
57 (13.9) 16.65 16.65 1.22 15.93 15.93 1.37 14.83 14.83 1.52 13.70 13.70 1.70 12.53 12.53 1.90 11.26 11.26 2.13
62 (16.7) 17.30 15.33 1.22 16.38 14.89 1.37 15.05 14.24 1.52 13.73 13.73 1.70 12.55 12.55 1.90 11.28 11.28 2.13
63 (17.2)†† 17.67 12.51 1.22 16.71 12.09 1.38 15.42 11.53 1.53 13.80 10.84 1.70 12.20 10.17 1.89 10.50 9.46 2.11
67 (19.4) 19.21 13.04 1.23 18.18 12.64 1.39 17.04 12.18 1.56 15.53 11.58 1.73 13.75 10.89 1.92 11.97 10.20 2.14
72 (22.2) 21.16 10.63 1.25 20.17 10.28 1.41 19.02 9.88 1.59 17.68 9.38 1.79 16.09 8.82 1.99 14.07 8.12 2.19
600
57 (13.9) 17.43 17.43 1.24 16.66 16.66 1.39 15.79 15.79 1.56 14.44 14.44 1.72 13.17 13.17 1.92 11.83 11.83 2.15
62 (16.7) 17.78 16.48 1.24 16.83 15.99 1.39 15.81 15.81 1.56 14.46 14.46 1.72 13.20 13.20 1.92 11.85 11.85 2.15
63 (17.2)†† 18.10 13.33 1.24 17.09 12.90 1.39 15.97 12.42 1.56 14.16 11.66 1.71 12.51 10.97 1.91 10.78 10.19 2.13
67 (19.4) 19.65 13.89 1.25 18.59 13.51 1.41 17.40 13.04 1.58 16.09 12.53 1.77 14.10 11.76 1.94 12.26 11.03 2.16
72 (22.2) 21.57 11.12 1.26 20.56 10.79 1.43 19.41 10.41 1.61 18.06 9.95 1.80 16.50 9.40 2.02 14.39 8.68 2.21
675
57 (13.9) 18.11 18.11 1.25 17.28 17.28 1.41 16.38 16.38 1.58 15.09 15.09 1.75 13.73 13.73 1.94 12.32 12.32 2.17
62 (16.7) 18.22 17.49 1.25 17.31 17.31 1.41 16.41 16.41 1.58 15.12 15.12 1.75 13.75 13.75 1.95 12.34 12.34 2.17
63 (17.2)†† 18.46 14.11 1.25 17.39 13.67 1.41 16.24 13.18 1.58 14.48 12.44 1.73 12.78 11.70 1.93 11.09 11.09 2.15
67 (19.4) 19.98 14.69 1.26 18.91 14.33 1.42 17.69 13.87 1.60 16.35 13.35 1.79 14.38 12.58 1.96 12.51 11.79 2.18
72 (22.2) 21.88 11.57 1.28 20.86 11.27 1.44 19.69 10.90 1.62 18.34 10.46 1.82 16.73 9.90 2.04 14.63 9.20 2.23
EVAPORATOR AIR
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM
EWB
°F(°C)
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Capacity MBtuh
Total
System
KW**
Total Sens‡ Total Sens‡ To t a l Sens‡ To t a l Sens‡ Tot a l Sens‡ Total Sens‡
25HCD324(A,W)**30 Outdoor Section With FB4CNF024 Indoor Section
700
57 (13.9) 22.27 22.27 1.62 21.36 21.36 1.82 20.01 20.01 2.01 18.55 18.55 2.25 17.03 17.03 2.51 15.40 15.40 2.81
62 (16.7) 23.17 20.79 1.63 22.02 20.23 1.83 20.58 19.52 2.03 18.58 18.58 2.25 17.06 17.06 2.51 15.42 15.42 2.81
63 (17.2)†† 23.65 16.96 1.63 22.45 16.42 1.83 21.09 15.82 2.05 18.86 14.86 2.25 16.76 13.96 2.50 14.55 13.00 2.79
67 (19.4) 25.62 17.65 1.66 24.33 17.13 1.86 22.96 16.57 2.09 21.15 15.84 2.32 18.89 14.94 2.55 16.55 14.01 2.83
72 (22.2) 28.04 14.27 1.70 26.88 13.86 1.91 25.54 13.37 2.14 23.99 12.83 2.40 22.07 12.12 2.68 19.47 11.20 2.92
800
57 (13.9) 23.24 23.24 1.65 22.28 22.28 1.86 21.18 21.18 2.08 19.52 19.52 2.29 17.86 17.86 2.55 16.14 16.14 2.85
62 (16.7) 23.74 22.26 1.66 22.55 21.65 1.86 21.23 21.23 2.08 19.55 19.55 2.29 17.89 17.89 2.55 16.17 16.17 2.85
63 (17.2)†† 24.17 18.01 1.67 22.92 17.47 1.87 21.53 16.86 2.08 19.35 15.93 2.29 17.13 14.97 2.54 14.90 13.98 2.82
67 (19.4) 26.14 18.72 1.69 24.87 18.26 1.90 23.40 17.68 2.13 21.78 17.03 2.37 19.36 16.08 2.59 16.93 15.10 2.87
72 (22.2) 28.50 14.87 1.73 27.33 14.48 1.94 25.98 14.01 2.17 24.43 13.49 2.43 22.48 12.81 2.71 19.90 11.92 2.97
900
57 (13.9) 24.05 24.05 1.69 23.03 23.03 1.89 21.91 21.91 2.12 20.37 20.37 2.34 18.61 18.61 2.60 16.76 16.76 2.89
62 (16.7) 24.25 23.56 1.69 23.07 23.07 1.89 21.94 21.94 2.12 20.40 20.40 2.34 18.64 18.64 2.60 16.81 16.81 2.89
63 (17.2)†† 24.60 19.04 1.69 23.29 18.48 1.90 21.88 17.87 2.12 19.70 16.93 2.32 17.49 15.95 2.57 15.23 14.83 2.85
67 (19.4) 26.54 19.73 1.72 25.26 19.31 1.93 23.76 18.77 2.16 22.10 18.10 2.41 19.74 17.16 2.63 17.27 16.11 2.90
72 (22.2) 28.85 15.42 1.76 27.68 15.06 1.97 26.31 14.61 2.20 24.75 14.11 2.46 22.87 13.52 2.74 20.25 12.62 3.01
See notes on page 17
25HCD3
