10
Compressors
Reference Size I nom. MHA LRA LRA (Y) LRA (S) 1 cp. LRA (S) 2 cp.
06NW2146S7N 39 48 69 344 109 125 -
06NW2174S7N 46 58 83 423 134 154 -
06NW2209S7N 56 71 101 506 160 260 350
06NW2250S7N 66 87 120 605 191 330 400
06NW2300S5N 80 104 144 715 226 370 420
06NW2300S5E 80+ 111 165 856 270 385 460
Legend:
06NW - Compressor for water-cooled units
N - Non-economized compressor
E - Economized compressor
INOM - Average current draw of the compressor at Eurovent conditions
MHA - Must hold amperes (maximum operating current) at 360 V
LRA - Locked rotor current with across-the-line start
LRA (Y) - Locked rotor current at reduced current (star/delta start-up mode)
LRA (S) 1 cp. - Start-up with reduced current with electronic starter (start-up duration 3 seconds max.) for one compressor per circuit
LRA (S) 2 cp. - Start-up with reduced current with electronic starter (start-up duration 3 seconds max.) for two compressors per circuit
