Detailed cooling capacities* continued
See notes on pg. 21.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38AYC024-33, 34 Outdoor Section With F(A,B)4BN(F,C)024 Indoor Section
700
72 25.4 12.8 1.92 24.4 12.5 2.09 23.4 12.2 2.28 22.2 11.7 2.49 21.0 11.3 2.72
67 23.2 16.5 1.88 22.2 16.1 2.05 21.2 15.7 2.23 20.1 15.2 2.44 19.0 14.8 2.66
63†† 21.6 16.0 1.85 20.6 15.5 2.01 19.6 15.1 2.20 18.6 14.7 2.40 17.5 14.2 2.62
62 21.2 19.9 1.84 20.3 19.4 2.01 19.4 18.9 2.19 18.5 18.4 2.39 17.5 17.5 2.62
57 20.7 20.7 1.83 20.0 20.0 2.00 19.2 19.2 2.19 18.4 18.4 2.39 17.5 17.5 2.62
800
72 25.5 13.2 1.95 24.7 13.0 2.13 23.8 12.8 2.32 22.5 12.3 2.54 21.3 11.9 2.76
67 23.7 17.5 1.92 22.6 17.1 2.09 21.5 16.7 2.28 20.4 16.3 2.48 19.2 15.8 2.70
63†† 21.9 16.9 1.89 21.0 16.5 2.06 19.9 16.1 2.24 18.9 15.7 2.44 17.8 15.2 2.66
62 21.7 21.2 1.89 20.8 20.7 2.05 19.9 19.9 2.24 19.1 19.1 2.44 18.2 18.2 2.67
57 21.5 21.5 1.88 20.8 20.8 2.05 19.9 19.9 2.24 19.1 19.1 2.44 18.2 18.2 2.67
900
72 25.5 13.6 1.98 25.0 13.6 2.17 24.0 13.4 2.37 22.7 12.9 2.58 21.4 12.5 2.81
67 23.9 18.5 1.96 22.9 18.1 2.14 21.8 17.7 2.32 20.6 17.3 2.52 19.5 16.8 2.74
63†† 22.2 17.9 1.93 21.2 17.5 2.10 20.2 17.1 2.28 19.1 16.6 2.48 17.9 16.1 2.70
62 22.2 22.2 1.93 21.4 21.4 2.10 20.5 20.5 2.29 19.6 19.6 2.49 18.6 18.6 2.72
57 22.2 22.2 1.93 21.4 21.4 2.10 20.5 20.5 2.29 19.6 19.6 2.49 18.7 18.7 2.72
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Unit
Size
Cooling
Indoor
Section
Unit
Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 024 0.99 1.01 FC4CNF 024 1.00 0.99
030 1.00 1.01 030 1.01 0.99
CC5A/CD5AW 024 0.99 1.01 FF1DNA 024 1.00 1.02
030 1.00 1.01 030 1.03 1.03
CE3AA 024 1.00 1.01 FG3AAA 024 0.98 1.01
030 1.02 1.02 FK4DNF 001 1.01 0.89
CF5AA 024 1.00 1.01 002 1.02 0.89
CK3BA 024 0.99 1.00 003 1.04 0.89
030 1.00 1.00
COILS + 58CV(A,X)070-12 FURNACE
CK5A/CK5BA 024 0.99 1.00 CC5A/CD5AA 030 1.00 0.91
030 1.00 1.00 CC5A/CD5AW 030 1.00 0.91
CK5A/CK5BW 024 0.99 1.00 CE3AA 030 1.01 0.91
030 1.00 1.00 CK3BA 030 1.00 0.91
F(A,B)4BN(F,C) 024 1.00 1.00 CK5A/CK5BA 030 1.00 0.91
030 1.02 1.00 CK5A/CK5BW 030 1.00 0.91
