Heat pump heating performance continued
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
* The Btuh heating capacity values shown are net integrated values from which the defrost effect has been subtracted. The Btuh heating from sup-
plement heaters should be added to those values to obtain total system capacity.
† The kW values include the compressor, outdoor fan motor, and indoor blower motor. The kW from supplement heaters should be added to these
values to obtain total system kilowatts.
EDB – Entering Dry-Bulb
System Design
1. Intended for outdoor installation with free air inlet and outlet. Outdoor fan external static pressure available is less than 0.01-in. wc.
2. Minimum outdoor operating air temperature for cooling mode without low-ambient operation accessory is 55°F (12.8°C).
3. Maximum outdoor operating air temperature for cooling mode is 125°F (51.7°C).
4. Minimum outdoor operating air temperature for heating mode is –30°F (–34.4°C).
5. Maximum outdoor operating air temperature for heating mode is 66°F (18.9°C).
6. For reliable operation, unit should be level in all horizontal planes.
7. Maximum elevation of indoor coil above or below base of outdoor unit is: indoor coil above = 50 ft, indoor coil below = 150 ft.
8. For interconnecting refrigerant tube lengths greater than 50 ft horizontal or 20 ft vertical differential, consult Residential Split-System Long-Line
Application Guideline available from equipment distributor.
9. For more than 36 in. of refrigerant tubing buried in the ground, consult your local distributor.
10. Use only copper wire for electric connection at unit. Aluminum and clad aluminum are not acceptable for the type of connector provided.
11. Mismatches of indoor coil capacity more than 1 size larger than outdoor unit capacity may result in inadequate indoor comfort.
INDOOR
AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES °F
–3 7 17 2737475767
Capacity
MBtuh†
Total
Power
Capacity
MBtuh†
Total
Power
Capacity
MBtuh†
Total
Power
Capacity
MBtuh†
Total
Power
Capacity
MBtuh†
Total
Power
Capacity
MBtuh†
Total
Power
Capacity
MBtuh†
Total
Power
Capacity
MBtuh†
Total
Power
EDB CFM Total Integ* kW† Total Integ* kW† Total Integ* kW† Total Integ* kW† Total Integ* kW† Total Integ* kW† Total Integ* kW† Total Integ* kW†
38AYC060-33, 34 Outdoor Section With FB4BNB070 Indoor Section
65
1750 28.6 26.3 4.31 33.8 31.0 4.48 39.4 35.9 4.65 45.5 40.4 4.85 52.6 47.9 5.09 60.7 60.7 5.38 70.0 70.0 5.76 80.7 80.7 6.25
2000 29.1 26.7 4.37 34.2 31.4 4.52 39.9 36.3 4.68 46.0 40.8 4.85 53.2 48.4 5.07 61.4 61.4 5.34 71.5 71.5 5.71 81.4 81.4 6.12
2250 29.5 27.1 4.44 34.6 31.8 4.57 40.3 36.7 4.72 46.5 41.3 4.88 53.7 48.9 5.08 62.0 62.0 5.35 71.6 71.6 5.71 81.1 81.1 6.02
70
1750 28.2 25.9 4.48 33.5 30.8 4.68 39.0 35.6 4.87 45.0 40.0 5.08 52.0 47.4 5.33 60.0 60.0 5.63 69.2 69.2 6.03 79.7 79.7 6.53
2000 28.6 26.3 4.54 33.9 31.2 4.72 39.5 36.0 4.89 45.6 40.5 5.08 52.7 47.9 5.31 60.7 60.7 5.59 70.1 70.1 5.96 80.7 80.7 6.46
2250 29.1 26.7 4.61 34.3 31.5 4.78 39.9 36.4 4.94 46.0 40.9 5.11 53.2 48.4 5.32 61.3 61.3 5.59 70.7 70.7 5.95 81.0 81.0 6.33
75
1750 27.6 25.4 4.67 33.2 30.5 4.89 38.7 35.3 5.10 44.6 39.6 5.32 51.5 46.9 5.59 59.3 59.3 5.90 68.4 68.4 6.30 78.7 78.7 6.82
2000 28.1 25.8 4.72 33.6 30.9 4.93 39.2 35.7 5.12 45.1 40.1 5.32 52.2 47.5 5.56 60.1 60.1 5.85 69.3 69.3 6.23 79.8 79.8 6.74
2250 28.5 26.3 4.79 34.0 31.3 4.99 39.6 36.1 5.16 45.6 40.5 5.34 52.7 47.9 5.57 60.6 60.6 5.84 70.0 70.0 6.21 80.5 80.5 6.70
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Heating
Indoor
Section Size
Heating
Capacity Power Capacity Power
CC5A/CD5AA 060 1.00 1.13 CK5A/CK5BT 060 1.00 1.03
CC5A/CD5AW 060 1.00 1.04 CK5A/CK5BX 060 1.00 1.02
CE3AA 060 1.00 1.04 COILS + 58CV(A,X)135-22 FURNACE
CK3BA 060 1.00 1.08 CC5A/CD5AA 060 1.00 1.14
CK5A/CK5BA 060 1.00 1.08 CC5A/CD5AW 060 1.00 1.07
CK5A/CK5BT 060 1.00 1.08 CE3AA 060 1.00 1.06
CK5A/CK5BX 060 1.00 1.04 CK3BA 060 1.00 1.03
F(A,B)4BN(F,B,C) 060 1.00 1.04 CK5A/CK5BA 060 1.00 1.03
FB4BNB 070 1.00 1.00 CK5A/CK5BT 060 1.00 1.03
FC4CN(F,B) 060 1.00 1.04 CK5A/CK5BX 060 1.00 1.02
FC4CNB 070 1.00 1.01
COILS + 58CV(A,X)155-22 FURNACE
FG3AAA 060 1.00 1.06 CC5A/CD5AA 060 1.00 1.14
FK4DNB 006 1.00 0.97 CC5A/CD5AW 060 1.00 1.06
COILS + 58CV(A,X)110-22 FURNACE CE3AA 060 1.00 1.06
CC5A/CD5AA 060 1.00 1.14 CK3BA 060 1.00 1.02
CE3AA 060 1.00 1.06 CK5A/CK5BA 060 1.00 1.02
CK3BA 060 1.00 1.03 CK5A/CK5BT 060 1.00 1.02
CK5A/CK5BA 060 1.00 1.03 CK5A/CK5BX 060 1.00 1.02
