Carrier 38CKX - Dimensions and Installation Notes

6
AIR DISCHARGE
AIR IN
A SQ
B
P
C
3
/8 IN.
(9.5mm) DIA
TIEDOWN
KNOCKOUTS
(2) PLACES
2
7
/8″
(73.0mm)
1
1
/4″
(31.8mm)
H
G
F
E
FIELD CONTROL SUPPLY  CONN
7
/
8
IN. (22.2mm) DIA 
HOLE
FIELD POWER SUPPLY CONN 7
/
8
IN. (22.2mm) DIA HOLE WITH 
1
1
/
8
IN. (28.6mm) DIA KNOCKOUT 
AND 1
3
/
8
IN. (34.9mm) DIA 
KNOCKOUT
3
/
8
IN. (9.5mm) DIA LIQUID 
LINE CONN
D DIA VAPOR LINE CONN
L
K
J
AIR IN
M
N
AIR DISCHARGE
AIR IN
AIR IN
AIR DISCHARGE
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS (mm)
MINIMUM
MOUNTING PAD
DIMENSIONS (In.)
024, 036
571.5 x 571.5 22-1/2 x 22-1/2
048, 060
762.0 x 762.0 30 x 30
A97007
Dimensions
NOTES: 1. Allow 30 In. (762.0mm) clearance to service side of unit, 48 In. (1219.2mm) above
unit, 6 In. (152.4mm) on one side, 12 In. (308.8mm) on remaining side, and 24 In. (609.6mm) between units for proper airflow.
2. Minimum outdoor operating ambient in cooling mode is 55°F (13°C), max 125°F
(52°C).
3. Series designation is the 13th position of the unit model number. 4. Center of gravity .
/
S.I.
UNIT SERIES
ABCDEFGHJKLMNP
SHIPPING
WEIGHT
mm mm mm mm mm mm mm mm mm mm mm mm mm mm kg
38CKX024
1 571.5 557.2 81.0 15.9 93.7 460.4 501.7 565.2 365.1 496.9 560.4 263.5 260.4 273.1 59.4
38CKX036
1 571.5 862.0 81.0 19.1 93.7 460.4 501.7 565.2 365.1 496.9 560.4 260.4 273.1 308.0 69.4
38CKX048
1 762.0 709.6 82.6 22.2 165.1 596.9 692.2 755.7 508.0 687.4 750.9 381.0 330.2 368.3 98.6
38CKX060
1 762.0 1014.4 82.6 22.2 165.1 596.9 692.2 755.7 508.0 687.4 750.9 393.7 374.7 381.0 101.2
