PART LIST OF OUTDOOR UNIT (Cont.)
QTY./UNIT
38KLE-H 38KLE-C
SR. DESCRIPTION PART NUMBER
14 22 28 32 14 22 28 32 39
19 ELECTRICAL BOX SUBASSY 36314064 1
36314019 1
36314020 1
36314045 1
36313908 1
36313904 1
36314021 1
36314022 1
36313907 1
19.1 DUAL CAPACITOR
19.1.1 Dual Capacitor 35 + 5 MFD/370 VAC 02400376 1 1
19.1.2 Dual Capacitor 45 + 5 MFD/370 VAC * 02400644 1 1
19.1.3 Dual Capacitor 50 + 5 MFD/440 VAC 02400379 1 1 1 1
19.1.4 Dual Capacitor 60 + 5 MFD/440 VAC 02400377 1
19.2 CONTACTOR FOR COMPRESSOR
19.2.1 Contactor 2 poles – 25 Amps 02400580 1 1 1 1 1 1 1 1
19.2.2 Contactor 2 poles – 30 Amps 02400572 1
19.3 TERMINAL BLOCKS
19.3.1 Terminal Block 6 Poles-30 Amps 02501433 1 1 1 1
19.3.2 Terminal Block 4 Poles-30 Amps 02501405 1 1 1 1 1
19.3.3 Terminal Block 3 Poles-30 Amps 02501315 1 1 1 1 1 1 1 1 1
19.4 COND. ELECTRICAL BOX 06307405 1 1 1 1 1 1 1 1 1
19.5 CAPACITOR CLAMP 06301283 1 1 1 1 1 1 1 1 1
19.6 SUPPORT - CABLES 02802523 1 1 1 1 1 1 1 1 1
19.7 ELECTRICAL WIRE HARNESS 02500886 1 1
02500887 1 1 1 1
02500888 1 1
02500873 1
19.8 STARTER FOR COMPRESSOR
19.8.1 PTC Starter Model SPP POW-R-PAK * 02501579 1 1
19.8.2 PTC Starter Model SPP5 02501578 1
20 REVERSING VALVE & ELECTRIC COIL
02200405 1 1 1
02200404 1
21 ACCUMULATOR 02301012 1
22 SENSOR – OUTDOOR COIL 02503121 1 1 1 1
23 TUBING
36319212 1
36319215 1
36319216 1
36319217 1
36319218 1
36319219 1
36319220 1
36319223 1
36319224 1
36319225 1
* Option for sizes 14,22 and 28
