Carrier 38KLE39-C - Part List of Outdoor Unit; Compressor C;W Grommets & Spacers; Condenser Coil Subassy.; Condenser Motor

12
10. PART LIST OF OUTDOOR UNIT
QTY./UNIT
38KLE-H 38KLE-C
SR. DESCRIPTION
PART
NUMBER
14 22 28 32 14 22 28 32 39
1 COMPRESSOR C/W GROMMETS & SPACERS
1.1 Mitsushita Comp. 2KS206DSBB04 01500235 1 1
1.2 Mitsushita Comp. 2JS324D3AB07 01500240 1 1
1.3 Mitsushita Comp. 2JS438D3FE02 01500241 1 1
1.4 Copeland Comp. CR37KQ-PFT 01500256 1 1
1.5 Copeland Comp. CR47KQ-PFZ 01500172 1
2 COND. BASE 08107402 1 1 1 1 1 1 1 1 1
3 SUPPORTING LEG ASSY 36314043 4 4 4 4 4 4 4 4 4
4 COND. PARTITION 06307407 1 1 1 1 1 1 1 1
06307436 1
5 CONDENSER COIL SUBASSY.
5.1 Cond. Coil 1 Row – 33.46” x 22” - 12FPI 02600227 1 1
5.2 Cond. Coil 1 Row – 33.46” x 22” - 15FPI 02600228 1 1
5.3 Cond. Coil 2 Row – 33.15” x 22” - 14FPI 02600229 1 1
5.4 Cond. Coil 2 Row – 33.15” x 22” - 15FPI 02600234 1 1
5.5 Cond. Coil 2 Row – 33.15” x 28” - 15FPI 02600231 1
6 CONDENSER MOTOR SUPPORT SUBASSY. 36318880 1 1 1 1 1 1 1 1 1
7 CONDENSER MOTOR
7.1 Motor 1/10 HP-880 RPM 02400154 1 1 1 1 1 1 1 1
7.2 Motor 1/5 HP-860 RPM 02400179 1
8 PROPELLER C/W SOCKET SCREW 8X8MM 02600441 1 1 1 1 1 1 1 1 1
9 ORIFICE PROPELLER 02803112 1 1 1 1 1 1 1 1 1
10 COND. SHROUD 08107406 1 1 1 1 1 1 1 1
06307435 1
21 CARRIER LOGO 02900615 1 1 1 1 1 1 1 1 1
12 HANDLE 02803110 1 1 1 1 1 1 1 1 1
13 GUARD PROPELLER 02803113 1 1 1 1 1 1 1 1 1
14 COND. BACK PANEL 06307409 1 1 1 1 1 1 1 1
06307434 1
15 COUPLING PANEL 06307410 1 1 1 1 1 1 1 1 1
16 SERVICE DOOR 02803106 1 1 1 1 1 1 1 1 1
17 COIL GUARD 02803114 1 1 1 1 1 1 1 1
02803115 1
18 COND. COVER 08107400 1 1 1 1 1 1 1 1 1
