6 Specifications subject to change without notice. 38MAR-04SI
DIMENSIONS (CONT)
Fig. 6 — Sizes 24K, 30K, and 36K
31.91 in (810mm)
17.90 in (455mm)
0.47 in (12mm)
15.81 in (402mm)
2.68 in (68mm)
4.27 in (109mm)
17.90 in (455mm)
0.94 in (24mm)
2.87 in (73mm)
26.49 in (673mm)
3.38 in (86mm)
15.85 in (403mm)
8.36 in (212mm)
7.38 in (188mm)
37.78 in (959mm)
