PERFORMANCE DATA (CONT.)
INSTANTANEOUS AND INTEGRATED HEATING RATINGS
38MVQ024--3 / 40MVQ024--3
Air Temperature
Entering Indoor
Unit _F(_C)
Indoor
Airflow
(CFM)
L --- M --- H
Item
Air Temperature Entering Outdoor Coil --- DB/WB _F(_C)
57/53 (13.89/11.67) 47/43 (8.33/6.11) 37/33 (2.78/0.56) 27/23 (---2.78/---5) 17/13 (---8.33/---10.56)
Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated
Rating Rating Rating Rating Rating Rating Rating Rating Rating Rating
55 (12.78)
625
Cap 25.79 25.79 22.58 22.58 19.52 17.77 16.24 14.42 13.28 12.11
kW 1.76 1.63 1.52 1.41 1.32
689
Cap 25.99 25.99 22.72 22.72 19.81 18.03 16.40 14.57 13.43 12.25
kW 1.70 1.58 1.49 1.38 1.30
774
Cap 26.14 26.14 22.85 22.85 20.12 18.31 16.65 14.78 13.59 12.39
kW 1.63 1.53 1.45 1.36 1.29
60 (15.56)
625
Cap 25.42 25.42 22.28 22.28 18.96 17.26 15.78 14.02 12.90 11.76
kW 1.84 1.71 1.58 1.47 1.37
689
Cap 25.61 25.61 22.42 22.42 19.26 17.53 15.98 14.19 13.00 11.85
kW 1.78 1.66 1.55 1.45 1.36
774
Cap 25.80 25.80 22.55 22.55 19.56 17.80 16.20 14.38 13.16 12.00
kW 1.72 1.61 1.51 1.42 1.34
65 (18.33)
625
Cap 25.02 25.02 21.92 21.92 18.39 16.74 15.36 13.64 12.39 11.29
kW 1.92 1.78 1.64 1.53 1.43
689
Cap 25.23 25.23 22.08 22.08 18.73 17.05 15.49 13.75 12.54 11.44
kW 1.87 1.73 1.61 1.50 1.42
774
Cap 25.44 25.44 22.26 22.26 19.03 17.32 15.71 13.95 12.70 11.58
kW 1.80 1.68 1.58 1.48 1.39
70 (21.11)
625
Cap 24.62 24.62 21.46 21.46 18.00 16.38 14.87 13.21 11.92 10.87
kW 2.01 1.86 1.71 1.59 1.49
689
Cap 24.82 24.82 21.68 21.68 18.24 16.60 15.01 13.33 12.07 11.00
kW 1.95 1.81 1.68 1.57 1.47
774
Cap 25.04 25.04 21.90 21.90 18.50 16.83 15.23 13.52 12.26 11.18
kW 1.89 1.76 1.64 1.54 1.45
75 (23.89)
625
Cap 24.18 8.66 20.85 20.85 17.46 8.66 14.38 12.77 11.43 10.43
kW 2.09 1.92 1.78 1.65 1.55
689
Cap 24.41 8.89 21.23 21.23 17.65 8.89 14.52 12.89 11.59 10.56
kW 2.04 1.88 1.74 1.63 1.53
774
Cap 24.64 24.64 21.49 21.49 17.96 16.34 14.74 13.09 11.75 10.71
kW 1.98 1.84 1.71 1.60 1.51
80 (26.67)
625
Cap 23.70 23.70 20.22 20.22 16.93 15.41 13.82 12.28 10.94 9.97
kW 2.16 1.99 1.84 1.71 1.60
689
Cap 23.94 23.94 20.59 20.59 17.17 15.62 14.01 12.44 11.08 10.11
kW 2.11 1.95 1.81 1.69 1.59
774
Cap 24.22 24.22 20.98 20.98 17.44 15.87 14.22 12.63 11.25 2.25
kW 2.06 1.91 1.78 1.67 1.57
Indicates Rating Condition (Integrated Capacity) Indicates Integrated Rating
Cap --- Heating Capacity (100 Btuh), Includes indoor f an motor heat
kW --- Total Power Input, includes compressor motor power input, outdoor fan motor power input, and indoor fan motor power input
Note: Integrated Capacity is maximum (instantaneous ) capacity less the effect of frost on the outdoor coil and the heat to defrost it.
38/40MVC, MVQ
