Carrier 38TSA - Technical Specifications; Electrical Data; Sound Power Levels

6
Electrical data
* Permissible limits of the voltage range at which unit will operate satisfactorily.
† If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70). The ampacity of nonmetallic-sheathed
cable (NM), trade name ROMEX, shall be that of 60°C (140°F) conductors, per the NEC (ANSI/NFPA 70) Article 336-26. If other than uncoated
(non-plated), 60 or 75°C (140 or 167°F) insulation, copper wire (solid wire for 10 AWG and smaller, stranded wire for larger than 10 AWG) is used,
consult applicable tables of the NEC (ANSI/NFPA 70).
‡ Length shown is as measured 1 way along wire path between unit and service panel for voltage drop not to exceed 2%.
** Time-delay fuse.
FLA — Full Load Amps
LRA — Locked Rotor Arms
MCA — Minimum Circuit Amps
RLA — Rated Load Amps
NOTE: Control circuit is 24-v on all units and requires external power source. Copper wire must be used from service disconnect to unit. All motors/
compressors contain internal overload protection.
Sound power (dBA)
UNIT SIZE-
SERIES V/PH
OPER VOLTS* COMPR
FAN
FLA MCA
60°C
MIN
WIRE
SIZE†
75°C
MIN
WIRE
SIZE†
60°C
MAX
LENGTH
(Ft)‡
75°C
MAX
LENGTH
(Ft)‡
MAX
FUSE**
CKT BKR
AMPSMax Min LRA RLA
024-30, 32
208/230/1 253 187
61.0 13.5 0.5 17.4 14 14 45 43 25
030-30, 32 72.5 14.7 0.8 19.2 14 14 41 39 30
036-30, 32 83.0 15.4 0.8 20.1 12 12 62 59 30
042-30, 32 105.0 18.6 1.1 24.4 10 10 81 77 40
UNIT
SIZE
SOUND
LEVEL
(dBA)
OCTAVE BAND CENTER FREQUENCY (Hz)
125 250 500 1000 2000 4000 8000
024 69 58.5 60 63.5 63.5 61 58 50.5
030 70 56 61 63 64.5 62.5 57.5 50
036 72 56.5 64 65 67 63 58.5 50
042 73 58.5 66.5 66 66.5 64.5 59 50.5
