Carrier 39LA - Page 22

22
Table 8 — Distributor Part Numbers
Table 9 — Side Connector (Hot Gas Bypass) Data
DIMENSIONS (in.)
LEGEND
PART NO.
NO.
OF
TUBES
CONNECTION
OD (in.)
SPORLAN
NOZZLE
Sporlan Carrier Type Size
1112-2-
1
/
4
EA07NC261 2
0.88 G
3
/
4
to 12
1112-3-
1
/
4
EA07FC027 3
1112-4-
1
/
4
EA07NC262 4
1112-5-
1
/
4
EA07NC263 5
1112-6-
1
/
4
EA07NC264 6
1113-7-
1
/
4
EA07HC207 7
1113-8-
1
/
4
EA07HC208 8
1115-8-
1
/
4
EA07KC240 8
1.12 E 3 to 30
1115-9-
1
/
4
EA07KC241 9
1115-10-
1
/
4
EA07KC242 10
1116-11-
1
/
4
EA07HC011 11
1117-11-
1
/
4
EA07LC510 11
1.38 C 3 to 50
1117-12-
1
/
4
EA07HC012 12
1117-13-
1
/
4
EA07HC013 13
1126-14-
1
/
4
EA07TC290 14
1126-15-
1
/
4
EA07HC015 15
1126-16-
1
/
4
EA07TC207 16
1126-17-
1
/
4
EA07HC017 17
SPORLAN
TYPE
CARRIER
PART NO.
CONNECTION SIZES (in.)
USED WITH
DISTRIBUTOR TYPE
NOZZLE
SIZE
Inlet — ODM Solder Outlet — ODF Solder Auxiliary — ODF Solder
ASC-5-4 —
5
/
8
5
/
8
1
/
2
1620, 1622 J
ASC-7-4 EA19BA504
7
/
8
7
/
8
1
/
2
1112, 1113 G
ASC-9-5 EA19BA705 1
1
/
8
1
1
/
8
5
/
8
1115, 1116 E
ASC-11-7 EA19BA905 1
3
/
8
1
3
/
8
7
/
8
1117, 1126 C
ASC-13-9 — 1
5
/
8
1
5
/
8
1
1
/
8
1125, 1127, 1143 A
SPORLAN
TYPE
ABCDEF
ASC-5-4
5
/
8
ODM
5
/
8
ODF 1.88 0.95 1.25
1
/
2
ODM
ASC-7-4
7
/
8
ODM
7
/
8
ODF 2.25 1.06 1.38
1
/
2
ODM
ASC-9-5 1
1
/
8
ODM 1
1
/
8
ODF 2.81 1.47 1.62 1
5
/
8
ODM
ASC-11-7 1
3
/
8
ODM 1
3
/
8
ODF 3.53 1.89 2.19 1
7
/
8
ODM
ASC-13-9 1
5
/
8
ODM 1
5
/
8
ODF 3.72 1.83 2.75 1
1
/
8
ODM
ODF — Outside Diameter, Female
ODM — Outside Diameter, Male
Fig. 27 — Expansion Valve Piping
Fig. 28 — Distributor and Hot Gas Bypass
Auxiliary Side Connector
