1.2 COM PRESSO R REFERENCE DATA
Model
TM 16 06VM306 06VM307
Displacement 163 cc 113 cc 130 cc
No. Cylinders 6 2 2
Weight 7kg 37 kg 47 kg
Oil Charge 250 ml 1200 ml 1200 ml
Approved oil POE -- Mobil Arctic EAL 68 (Carrier Part Number 46-60002-02)
1.3 REF RI GERATION SYSTEM DATA
a. Defrost Timer
Automatic triggering or at present intervals :
0, auto, 1h, 2h, 3h, 4h, 5h, 6h
b. Defrost Termination Thermostat
Opens at: 48_ ¦ 5_F(9_ ¦ 3_C)
Closes at: 37_ ¦ 5_F(3_ ¦ 3_C)
c. High Pressure Switch (HP1)
Cutout at : 465 ¦ 10 psig (32 bar)
Cut-in at : 360 ¦ 10 psig (25 bar)
d. Condenser Pressure Switch (HP2)
Cutout at : 245 ¦ 10 psig1 (7 bar)
Cut-in at : 320 ¦ 10 psig (22 bar)
e. Standby High Pressure Switch (HP3)
Cutout at : 430 ¦ 10 psig (30 bar)
Cut-in at : 360 ¦ 10 psig (25 bar)
f. Refrigerant charge
RefertoTable1-1.
g. Compressor Pressure Regulating Valve (CPR)
Setting; 36 ¦ 1psig(2.5bar)
h. Thermostatic Expansion Valve
T ype: 50S = TES 2/ Orifice n_4/ MOP 75psi (5.1 bar)
40S = TES 2/ Orifice n_3/ MOP 75 psi (5.1 bar)
Superheat setting = 7 ¦ 1_F(4_C)at0_F(-20_C) box
temperature.
i. Low Pressure Switch (LP)
Cutout at : -2.9 psig ¦ 3 psi (-0.2 bar)
Cut-in at : 14.5 psig ¦ 3 psi (1 bar)
j. Quench Valve (BPV)
Opens at: 260_F (127_C)
Closes at: 212_F (105_C)
1.4 ELECTRICAL DATA
a. Evaporator Fan Motors
Bearing Lubrication
Factory Lubricated
Horse Power 0.1 kw
Operating Amps 7to9amps
Speed 2100 rpm (rated)
b. Standby Compressor Speed
-- 1740 rpm -- 60 hz
