Table 5 — Point Check
ENQUIRY INFORMATION DISPLAY VALUE MEANING REMARK
T1,T2,T3,T4,
T2B,TP,TH,
Targeted
Frequency,
Actual
Frequency
-1F,-1E,-1d,-1c,-1b,-1A -25,-24,-23,-22,-21,-20 1. The displaying temperature is the actual
value.
2. The temperature is °C no matter what kind
of remote control is used.
3. T1,T2,T3,T4,T2B display range:-25~70, TP
display range:-20~130.
4. Frequency display range: 0~159HZ.
5. If the actual value exceeds the range, it
displays the maximum value or minimum
value.
-19—99 -19—99
A0,A1,…A9 100,101,…109
b0,b1,…b9 110,111,…119
c0,c1,…c9 120,121,…129
d0,d1,…d9 130,131,…139
E0,E1,…E9 140,141,…149
F0,F1,…F9 150,151,…159
Indoor fan speed
/Outdoor fan speed
0OFF
1,2,3,4
Low speed, Medium speed, High speed,
Turbo
For some big capacity motors
14-FF
Actual fan speed = Display value turns to
decimal value and then multiply by 10. The
unit is RPM.
For some small capacity motors, the display
value is from 14-F (hexadecimal), the
corresponding fan speed range is from 200-
2550 RPM.
EXV opening angle 0-FF
Actual EXV opening value = Display value turns to
decimal value and then multiply by 2.
Compressor continuous
running time
0-FF 0-255 minutes
If the actual value exceeds the range, it
displays the maximum value or minimum
value.
Compressor stop causes 0-99
For a detailed meaning, please consult with
an engineer.
Decimal display
Reserve 0-FF
