DISASSEMBLY INSTRUCTIONS (CONT)
Display Board
Procedure Illustration
1) Remove 1 screw then remove the
display box subassembly.
2) Pry open the display light box.
3) Remove the display board and the
humidity sensor module.
Humidity sensor module
Display board
