40MBFAQ: Service Manual
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
48
DISASSEMBLY INSTRUCTIONS (CONT)
Electrical Parts (Anti-static gloves must be worn)
NOTE: Remove the front panel and the panel frame subassembly before disassembling the electrical parts.
Procedure Illustration
1) Remove 1 screw and remove the
electronic control box cover.
2) Pull out the electrical main board.
To Next Page
