CLEARANCES -- OUTDOOR
A
D
B
Air-outlet
Air-inlet
C
E
Fig. 6 – Outdoor Unit Clearance
Table 6—Outdoor
UNIT
Minimum Value
in. (mm)
A 24 (609)
B 24 (609)
C 24 (609)
D 4 (101)
E 4 (101)
