Carrier 40MBQB09D-3 Service Manual

12
ELECTRICAL DATA
Table 7—High Wall
UNIT SIZE
System Voltage OPERATING VOLTAGE INDOOR FAN
VOLT/PHASE/HZ MAX / MIN V--PH--HZ FLA HP W
9
208--230/1/60 253 / 187 208 --230/1/60
0.07 0.027 20
12
0.07 0.027 20
18
0.17 0.077 58
24
0.23 0.08 60
30
0.23 0.08 60
Table 8—Ducted
UNIT SIZE
System Voltage OPERATING VOLTAGE INDOOR FAN
VOLT/PHASE/HZ MAX / MIN FLA HP W
9
208--230/1/60 253 / 187
1.03 0.073 55
12 1.03 0.073 55
18 0.83 0.12 90
24 0.83 0.12 90
36 1.263 0.2 150
48 2.23 0.32 240
Table 9—Cassette
Cassette
UNIT SIZE
System Voltage OPERATING VOLTAGE INDOOR FAN
VOLT/PHASE/HZ MAX / MIN V--PH--HZ FLA HP W
9
208--230/1/60 253 / 187 208 --230/1/60
0.146 0.061 46
12
0.146 0.061 46
18
0.146 0.061 46
Table 10—Floor Console
UNIT SIZE
System Voltage OPERATING VOLTAGE INDOOR FAN
VOLT/PHASE/HZ MAX / MIN V--PH--HZ FLA HP W
9
208--230/1/60 253 / 187 208 --230/1/60
0.21 0.027 20
12
0.21 0.027 20
Table 11—Multi Zone Outdoor Unit
UNIT SIZE
System Voltage OPERATING VOLTAGE COMPRESSOR OUTDOOR FAN MCA
MAX
FUSE/CB
AMP
VOLT/PHASE/HZ MAX / MIN RLA FLA HP W
18
208--230/1/60 253 / 187
9.7
3 0.16 50 15 20
27 8.85
3 0.16 120 19 25
36 13.4
3 0.16 120 27 40
48 13.5
3 0.11 85 29 50
*Permissible limits of the voltage range at which the unit will operate satisfactorily.
LEGEND
FLA -- F u l l L o a d A m p s
MCA -- Minimum Circuit Amps
RLA --RatedLoadAmps
