Carrier 40MBQB09D-3 Service Manual

6
PHYSICAL DATA -- OUTDOOR
Table 4—Outdoor
System
Size 18 27 36 48
Outdoor Model
3 8 M G Q C 1 8 -- -- -- 3
538TEQ018RCMA
38MGQD27------3
538TEQ027RDMA
3 8 M G Q F 3 6 -- -- -- 3
538TEQ036RFMA
3 8 M G Q F 4 8 -- -- -- 3
538TEQ048RFMA
Max Number of Zones 2 3 4 5
Energy Star YES YES NO YES
Performance
Non--Ducted
Cooling Rated Capacity Btu/h 18,000 25,000 36,000 42,000
Cooling Cap. Range Min -- Max Btu/h 8,500~20,000 9,000~30,000 9,500~37,000 10,000~50,000
SEER 21 22 18 20
EER 12.5 12.5 8.8 12.5
Heating Rated Capacity Btu/h 18,500 32,000 36,000 49,000
Heating Cap. Range Min -- Max Btu/h 9,000~22,000 9,500~32,000 10,000~39,000 10,500~55,000
HSPF 9.6 9.6 10.0 10.0
Performance
Combination
Ducted and
Non--Ducted
Cooling Rated Capacity Btu/h 17,500 26,000 35,000 42,000
Cooling Cap. Range Min -- Max Btu/h 8,500~20,000 9,000~30,000 9,500~36,500 10,000~50,000
SEER 19.5 19.25 16.5 19
EER 12.5 11 8.5 11.75
Heating Rated Capacity Btu/h 18,250 32,000 36,000 50,000
Heating Cap. Range Min -- Max Btu/h 9,000~22,000 9,500~32,000 10,000~39,000 10,500~55,000
HSPF 9.1 9.2 9.7 9.8
Performance
Ducted
Cooling Rated Capacity Btu/h 17,000 27,000 34,000 42,000
Cooling Cap. Range Min -- Max Btu/h 8,500~20,000 9,000~30,000 9,500~36,000 10000~50000
SEER 18 16.5 15 18
EER 12.5 9.5 8.2 11
Heating Rated Capacity Btu/h 18,000 32,000 36,000 51,000
Heating Cap. Range Min -- Max Btu/h 9000~22000 9500~32000 10,000~39,000 10,500~55,000
HSPF 8.5 8.8 9.3 9.5
Operating
Range
Cooling Outdoor DB Min -- Max F 4~122 4~122 4~122 4~122
Heating Outdoor DB Min -- Max  F 4~86 4~86 4~86 4~86
Piping
Total Piping Length Ft. 98 147 196 245
Piping to furthest FCU Ft. 98 98 98 98
Drop (OD above ID) Ft. 32 32 32 32
Lift (OD below ID) Ft. 32 32 32 32
Pipe Connection Size -- Liquid In. 1/4*2 1/4*3 1/4*4 1/4*5
Pipe Connection Size -- Suction In. 3/8*2 3/8*3 1/2+3/8*3 1/2*2+3/8*3
Electrical
Voltage, Phase, Cycle V/Ph/Hz 208/230 --1 --60 208/230--1--60 208/230 --1 --60 208/230 --1--60
Power Supply Indoor unit powered from outdoor unit
MCA A. 15 19 27 29
MOCP -- Fuse Rating A. 20 25 40 50
Outdoor
Unit Width In. 33.3 37.2 37.2 36.9
Unit Heigh t In. 27.6 31.9 31.9 53.9
Unit Depth In. 12.6 15.6 15.6 15.4
Net Weight Lbs. 114.6 154.8 169.8 255.5
Airflow CFM 1,390 2,130 2,130 3,500
Sound Pressure dB(A) 60 63 63 64
